ASHCROFT Pressure Transmitter: 0 psi to 200 psi, 1 to 5V DC - Pressure Transmitters with 4-Pin Mini-DIN Connector
ASHCROFTPressure Transmitters with 4-Pin Mini-DIN Connector

ASHCROFT Pressure Transmitter: 0 psi to 200 psi, 1 to 5V DC

The ASHCROFT G2 Series Pressure Transmitter (0 psi to 200 psi) is a pressure transmitter with a 4-Pin Mini-DIN connector, featuring a 1 to 5V DC output. It offers ±0.5% accuracy, an IP67 and NEMA 4X rating, and a…

SKU 3G-OTH-176231

Brand
ASHCROFT
Item
Pressure Transmitter: 0 psi to 200 psi, 1 to 5V DC
Category
Pressure Transmitters with 4-Pin Mini-DIN Connector
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
G17M0115M1200#
Series
G2
Type
4-Pin Mini-DIN Hirschmann G Series Connector
DC
1 to 5V
Output
1 to 5V DC
Accuracy
±0.5%
IP Rating
IP67
NEMA Rating
4X
Overpressure
2x Range
Burst Pressure
10x Range
Housing Material
Nylon
Process Connection Type
NPT
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT G2 Series Pressure Transmitter (0 psi to 200 psi) is a pressure transmitter with a 4-Pin Mini-DIN connector, featuring a 1 to 5V DC output. It offers ±0.5% accuracy, an IP67 and NEMA 4X rating, and a nylon housing with a male NPT process connection. Overpressure capability is 2x range, with a burst pressure of 10x range.

Frequently Asked Questions

What is the ASHCROFT G2 pressure transmitter used for?

The ASHCROFT G2 pressure transmitter measures pressure from 0 psi to 200 psi and outputs a 1 to 5V DC signal. It is used in industrial process control, HVAC, and hydraulic systems where a reliable, compact transmitter with IP67 and NEMA 4X protection is required.

What are the specifications of the ASHCROFT G2 pressure transmitter?

The ASHCROFT G2 pressure transmitter (MPN G17M0115M1200#) has an accuracy of ±0.5%, output of 1 to 5V DC, overpressure of 2x range, burst pressure of 10x range, IP67 and NEMA 4X ratings, and a nylon housing with a male NPT process connection.

Where to buy the ASHCROFT G2 pressure transmitter worldwide?

You can source the ASHCROFT G2 pressure transmitter through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the ASHCROFT G2 pressure transmitter?

Install the ASHCROFT G2 pressure transmitter by connecting the male NPT process connection to a compatible port, ensuring a proper seal. Wire the 4-Pin Mini-DIN connector per the 1 to 5V DC output requirements. Avoid exceeding the 2x range overpressure limit to prevent damage.
