ASHCROFT Pressure Transmitter: 0 psi to 500 psi, 1 to 5V DC - Pressure Transmitters with 4-Pin Mini-DIN Connector
ASHCROFTPressure Transmitters with 4-Pin Mini-DIN Connector

ASHCROFT Pressure Transmitter: 0 psi to 500 psi, 1 to 5V DC

The ASHCROFT G2 Series Pressure Transmitter (0 psi to 500 psi) is a pressure transmitter with a 4-Pin Mini-DIN connector, offering a 1 to 5V DC output. Key specifications include ±0.5% accuracy, IP67 and NEMA 4X…

SKU 3G-OTH-176267

Brand
ASHCROFT
Item
Pressure Transmitter: 0 psi to 500 psi, 1 to 5V DC
Category
Pressure Transmitters with 4-Pin Mini-DIN Connector
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
G17MEK15M1500#
Series
G2
Type
4-Pin Mini-DIN Hirschmann G Series Connector
DC
1 to 5V
Output
1 to 5V DC
Accuracy
±0.5%
IP Rating
IP67
NEMA Rating
4X
Overpressure
2x Range
Burst Pressure
10x Range
Housing Material
Nylon
Process Connection Type
SAE
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT G2 Series Pressure Transmitter (0 psi to 500 psi) is a pressure transmitter with a 4-Pin Mini-DIN connector, offering a 1 to 5V DC output. Key specifications include ±0.5% accuracy, IP67 and NEMA 4X ratings, overpressure of 2x range, burst pressure of 10x range, a nylon housing, and a male SAE process connection.

Frequently Asked Questions

What is the ASHCROFT G2 pressure transmitter used for?

The ASHCROFT G2 pressure transmitter measures pressure from 0 psi to 500 psi and outputs a 1 to 5V DC signal. It is used in industrial applications requiring IP67 and NEMA 4X protection, such as hydraulic systems, pumps, and process control, where a 4-Pin Mini-DIN Hirschmann G Series connector is needed.

What are the specifications of the ASHCROFT G2 pressure transmitter?

The ASHCROFT G2 pressure transmitter (MPN G17MEK15M1500#) has a range of 0 psi to 500 psi, accuracy of ±0.5%, output of 1 to 5V DC, IP67 and NEMA 4X ratings, overpressure of 2x range, burst pressure of 10x range, nylon housing, and a male SAE process connection with a 4-Pin Mini-DIN Hirschmann G Series connector.

Where to buy the ASHCROFT G2 pressure transmitter worldwide?

3G Electric supplies the ASHCROFT G2 pressure transmitter worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time. We source and deliver this transmitter to support your operations anywhere.

How to select the right ASHCROFT G2 pressure transmitter for my system?

To select the ASHCROFT G2 pressure transmitter, verify your system's pressure range (0 psi to 500 psi), output signal requirement (1 to 5V DC), and connector type (4-Pin Mini-DIN Hirschmann G Series). Ensure the process connection is male SAE and that environmental ratings (IP67, NEMA 4X) match your installation conditions.

Used in

Common applications for ASHCROFT
Process control in chemical plants — ASHCROFT G2 series pressure transmitters with 4-20 mA output
Sanitary monitoring in food processing — ASHCROFT sanitary pressure transmitters with stainless steel fittings
Temperature measurement in oil and gas — ASHCROFT flanged thermowells rated to 1,000°F
Hydraulic system pressure monitoring — ASHCROFT G2 series transmitters with 1-5 V DC output
Hazardous location pressure sensing — ASHCROFT A2X explosion-proof transmitters with conduit connection
Steam system temperature protection — ASHCROFT threaded thermowells rated to 7,000 psi

ASHCROFT Products

3G Electric supplies ASHCROFT pressure transmitters with 4-pin mini-din connector. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
