ASHCROFT Pressure Transmitter - Explosion-Proof with Conduit Connection & Wire Leads
ASHCROFTExplosion-Proof with Conduit Connection & Wire Leads

ASHCROFT Pressure Transmitter

The ASHCROFT E2F Series Pressure Transmitter (MPN E2FA5NM0442CFX03F1000#) is an explosion-proof gauge pressure transmitter with a 1,000 psi range and a 4 to 20mA output. It features a stainless steel housing, IP66…

SKU 3G-OTH-175394

Brand
ASHCROFT
Item
Pressure Transmitter
Category
Explosion-Proof with Conduit Connection & Wire Leads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
E2FA5NM0442CFX03F1000#
Series
E2F
Output
4 to 20mA
Accuracy
±0.50%
IP Rating
IP66
NEMA Rating
4X
Overpressure
2x
Safety Rating
Class I, Div 1, Group A, B, C, D
Burst Pressure
8x
Housing Material
Stainless Steel
Intrinsically Safe
Not Specified Intrinsically Safe
Electrical Connection
1/2 in NPT Conduit with Cable
Pressure Type Measured
Gauge
Process Connection Type
NPT
NIST Traceable Certificate
No NIST-Traceable Calibration Certificate Included
Resistance Properties - TS Only
Vibration Resistant
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT E2F Series Pressure Transmitter (MPN E2FA5NM0442CFX03F1000#) is an explosion-proof gauge pressure transmitter with a 1,000 psi range and a 4 to 20mA output. It features a stainless steel housing, IP66 and NEMA 4X ratings, a 1/2 in NPT conduit electrical connection with cable, and an NPT process connection. The transmitter offers ±0.50% accuracy, 2x overpressure and 8x burst pressure protection, and is rated Class I, Div 1, Group A, B, C, D for hazardous locations.

Frequently Asked Questions

What is the ASHCROFT E2F pressure transmitter used for?

The ASHCROFT E2F Series pressure transmitter is used for gauge pressure measurement in hazardous locations requiring explosion-proof protection. It is suitable for industrial applications such as oil and gas, chemical processing, and power generation where Class I, Div 1, Group A, B, C, D ratings are needed.

What are the specifications of the ASHCROFT E2F pressure transmitter?

The ASHCROFT E2F transmitter (MPN E2FA5NM0442CFX03F1000#) has a 1,000 psi range, 4 to 20mA output, ±0.50% accuracy, stainless steel housing, IP66 and NEMA 4X ratings, 1/2 in NPT conduit electrical connection, and NPT process connection. It offers 2x overpressure and 8x burst pressure protection.

Where to buy ASHCROFT E2F pressure transmitter worldwide?

3G Electric supplies the ASHCROFT E2F pressure transmitter worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this explosion-proof transmitter.

How to install the ASHCROFT E2F pressure transmitter?

Install the ASHCROFT E2F pressure transmitter by connecting the NPT process connection to the system, wiring the 4 to 20mA output through the 1/2 in NPT conduit, and ensuring the housing is sealed for IP66/NEMA 4X protection. Follow standard hazardous location installation practices for Class I, Div 1 areas.

Used in

Common applications for ASHCROFT
Process control in chemical plants — ASHCROFT G2 series pressure transmitters with 4-20 mA output
Sanitary monitoring in food processing — ASHCROFT sanitary pressure transmitters with stainless steel fittings
Temperature measurement in oil and gas — ASHCROFT flanged thermowells rated to 1,000°F
Hydraulic system pressure monitoring — ASHCROFT G2 series transmitters with 1-5 V DC output
Hazardous location pressure sensing — ASHCROFT A2X explosion-proof transmitters with conduit connection
Steam system temperature protection — ASHCROFT threaded thermowells rated to 7,000 psi

ASHCROFT Products

3G Electric supplies ASHCROFT explosion-proof with conduit connection & wire leads. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
