ASHLAND CONVEYOR Conveyor Guard Rail: For 90° Curve Frame Shape, 36 in Radius x 22 in BF - Metal Conveyor Guard Rails
ASHLAND CONVEYORMetal Conveyor Guard Rails

ASHLAND CONVEYOR Conveyor Guard Rail: For 90° Curve Frame Shape, 36 in Radius x 22 in BF

The ASHLAND CONVEYOR Conveyor Guard Rail is a metal guard rail designed for a 90° curve frame shape. This light-duty steel guide rail has an inside radius of 36 in and a curve between frame of 22 in BF, and includes…

SKU 3G-OTH-358705

Brand
ASHLAND CONVEYOR
Item
Conveyor Guard Rail: For 90° Curve Frame Shape, 36 in Radius x 22 in BF
Category
Metal Conveyor Guard Rails
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHLAND CONVEYOR
Manufacturer Part Number
GU39022R36
Type
36 in Radius x 22 in BF, Steel
Includes
Hardware
Component Type
Metal Guard Rail
Guide Material
Steel
For Conveyor Duty Rating
Light-Duty
Inside Radius x Curve Between Frame
36 in Radius x 22 in BF
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHLAND CONVEYOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHLAND CONVEYOR Conveyor Guard Rail is a metal guard rail designed for a 90° curve frame shape. This light-duty steel guide rail has an inside radius of 36 in and a curve between frame of 22 in BF, and includes hardware.

Frequently Asked Questions

What is the ASHLAND CONVEYOR Conveyor Guard Rail used for?

The ASHLAND CONVEYOR Conveyor Guard Rail is used to guide products safely around a 90° curve on light-duty conveyor systems. It prevents items from falling off the conveyor edge, reducing damage and downtime in material handling operations.

What are the specifications of the ASHLAND CONVEYOR Conveyor Guard Rail?

This guard rail is a steel metal guard rail for a 90° curve frame shape. It has an inside radius of 36 in and a curve between frame of 22 in BF. It is rated for light-duty conveyor use and includes hardware. The manufacturer part number is GU39022R36.

Where to buy the ASHLAND CONVEYOR Conveyor Guard Rail worldwide?

You can source the ASHLAND CONVEYOR Conveyor Guard Rail through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide locations, ensuring the part reaches your facility reliably.

How to install the ASHLAND CONVEYOR Conveyor Guard Rail?

Install the guard rail by aligning it with the 90° curve of your conveyor frame. Use the included hardware to secure it firmly. Ensure the inside radius of 36 in matches your conveyor curve. Follow standard safety practices for conveyor guard installation.

Used in

Common applications for ASHLAND CONVEYOR
Assembly line material transport — ASHLAND CONVEYOR SB400 slider bed belt conveyor for light-duty parts movement
Warehouse package handling — ASHLAND CONVEYOR RB190 roller bed belt conveyor for medium-duty carton transport
Conveyor system elevation adjustment — ASHLAND CONVEYOR H15M94B22 H-style support stand for 22-inch frame width
Multi-level conveyor installation — ASHLAND CONVEYOR HMTB10 multi-tier support stand for 10-inch between-frame width
Low-clearance conveyor support — ASHLAND CONVEYOR LP25M4.7 low-profile stand for 4 3/8 to 5 inch height
