ATC DIVERSIFIED ELECTRONICS Time-Delay Relay: 4 Pins/Terminals
The ATC DIVERSIFIED ELECTRONICS Time-Delay Relay (MPN CP-15M-A) is a socket-mounted relay with 4 pins/terminals and a time-delay range of 15 min to 60 min. It features a contact rating of 20 A @ 240V AC.
SKU 3G-OTH-43289
Also listed as: CP15MA · CP 15M A
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
The ATC DIVERSIFIED ELECTRONICS Time-Delay Relay (MPN CP-15M-A) is a socket-mounted relay with 4 pins/terminals and a time-delay range of 15 min to 60 min. It features a contact rating of 20 A @ 240V AC.
Frequently Asked Questions
What is the ATC DIVERSIFIED ELECTRONICS CP-15M-A time-delay relay used for?
The ATC DIVERSIFIED ELECTRONICS CP-15M-A is a socket-mounted time-delay relay used in industrial control panels to delay power to a load for 15 to 60 minutes. Common applications include motor start sequencing, conveyor system timing, and HVAC equipment staging where a timed interval is required.
What are the specifications of the ATC DIVERSIFIED ELECTRONICS CP-15M-A?
The ATC DIVERSIFIED ELECTRONICS CP-15M-A is a socket-mounted relay with 4 pins/terminals. Its time-delay range is 15 min to 60 min. The contact rating is 20 A @ 240V AC. The manufacturer part number is CP-15M-A. It is designed for industrial timing applications.
Where to buy the ATC DIVERSIFIED ELECTRONICS CP-15M-A worldwide?
3G Electric supplies the ATC DIVERSIFIED ELECTRONICS CP-15M-A time-delay relay to customers worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.
How to install the ATC DIVERSIFIED ELECTRONICS CP-15M-A time-delay relay?
To install the ATC DIVERSIFIED ELECTRONICS CP-15M-A, first ensure power is off. Plug the relay into a compatible socket, matching pin orientation. Set the time-delay dial to the desired interval between 15 and 60 minutes. Wire the load to the relay's normally open contacts rated 20 A @ 240V AC. Test operation before finalizing.
