B-LINE BY EATON Hammer-On Beam Clamp: Steel, 1/8 in to 1/4 in, 1/4"-20 Thread Size - Beam, Wire Rod & Purlin Clamps
B-LINE BY EATONBeam, Wire Rod & Purlin Clamps

B-LINE BY EATON Hammer-On Beam Clamp: Steel, 1/8 in to 1/4 in, 1/4"-20 Thread Size

The B-LINE BY EATON Hammer-On Beam Clamp is a steel beam, wire rod and purlin clamp with a zinc-plated finish. It features a 1/4"-20 thread size, a 75 lb load capacity, and is designed for beam flange thicknesses of…

SKU 3G-OTH-04688

Brand
B-LINE BY EATON
Item
Hammer-On Beam Clamp: Steel, 1/8 in to 1/4 in, 1/4"-20 Thread Size
Category
Beam, Wire Rod & Purlin Clamps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

B-LINE BY EATON
Type
1/8 in to 1/4 in
Finish
Zinc Plated
UNSPSC
39121311
Includes
20 x 0.38 in Ked Stud
Ked Stud
20 x 0.38 in
Material
Steel
Standards
UL/CUL
Thread Size
1/4"-20
For Use With
Boxes
Load Capacity
75 lb
Overall Width
1 in
Mounting Style
Hammer On
Overall Height
1 in
Overall Length
1 in
Country of Origin
USA (subject to change)
Compatible Pipe Size
1/4 in
Beam Flange Thickness
1/8 in to 1/4 in
Compatible Product Type
Pipe
Manufacturer Part Number
BU-2-4-S
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

B-LINE BY EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The B-LINE BY EATON Hammer-On Beam Clamp is a steel beam, wire rod and purlin clamp with a zinc-plated finish. It features a 1/4"-20 thread size, a 75 lb load capacity, and is designed for beam flange thicknesses of 1/8 in to 1/4 in. The clamp includes 20 x 0.38 in Ked Studs and is UL/CUL listed.

Used in

Common applications for B-LINE BY EATON
Data center cable management — B-Line by Eaton J-hooks (e.g., BCH21) for routing fiber and copper bundles above drop ceilings.
Industrial plant conduit support — B-Line by Eaton beam mount J-hooks (e.g., BCH32-C2) for securing electrical conduit to structural steel.
Commercial building ceiling grid — B-Line by Eaton extended angle brackets (e.g., BCH-HBA) for mounting J-hooks to threaded rods.
Telecommunications infrastructure — B-Line by Eaton wall mount J-hooks (e.g., BCH21) for cable runs along perimeter walls.
Manufacturing facility cable tray — B-Line by Eaton conduit clips (e.g., BW-16) for securing conduit to drop wire rods.
Power distribution systems — B-Line by Eaton hammer-on J-hooks (e.g., BCH12-U-2-4) for quick attachment to I-beams in electrical rooms.

B-LINE BY EATON Products

3G Electric supplies B-LINE BY EATON beam, wire rod & purlin clamps. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.

You might also need

Burners & Combustion →Pumps & Compressors →Spare Parts →All Products →

Similar products

Matched by specification & description
Beam Clamp: Steel, 1/4"-20 Thread Size, 1.35 in Overall Lg, 60 lb Load Capacity (MPN 2524). Key specifications — Load Capacity: 60 lb; Overall Length: 1.35 in; Overall Width: 1.2 in; Overall Height: 1.35 in; Material: Steel; Thread Size: 1/4"-20; Mounting Location: Beam; Standards: cULus Listed.
RACO
Beam Clamp: Steel, 1/4"-20 Thread Size, 1.35 in Overall Lg, 60 lb Load Capacity (MPN 2524). Key specifications — Load Capacity: 60 lb; Overall Length: 1.35 in; Overall Width: 1.2 in; Overall Height: 1.35 in; Material: Steel; Thread Size: 1/4"-20; Mounting Location: Beam; Standards: cULus Listed.
Beam Clamp with Conduit & Pipe Hanger: Steel, 1/2 in, 1/2 in to 3/4 in Trade Size (MPN BG-8-12-C2). Key specifications — Compatible Conduit Type: EMT; RMC; Nominal Conduit/Pipe/Threaded Rod: 1/2 in to 3/4 in; Beam Flange Thickness: 1/2 in; Material: Steel; Finish: Zinc Plated; For Use With: #10-24 Electrical Boxes; #10-24 Threaded Bridle Rings.
B-LINE BY EATON
Beam Clamp with Conduit & Pipe Hanger: Steel, 1/2 in, 1/2 in to 3/4 in Trade Size (MPN BG-8-12-C2). Key specifications — Compatible Conduit Type: EMT; RMC; Nominal Conduit/Pipe/Threaded Rod: 1/2 in to 3/4 in; Beam Flange Thickness: 1/2 in; Material: Steel; Finish: Zinc Plated; For Use With: #10-24 Electrical Boxes; #10-24 Threaded Bridle Rings.
Hammer-On Beam Clamp: Steel, 1/8 in to 1/4 in, 200 lb Load Capacity (MPN 4H24). Key specifications — Beam Flange Thickness: 1/8 in to 1/4 in; Load Capacity: 200 lb; Material: Steel; Finish: Corrosion Resistant Coated; Color: Silver; Mounting Orientation: Side Mount; Mounting Style: Hammer On; For Use With: Bolting Straps.
NVENT CADDY
Hammer-On Beam Clamp: Steel, 1/8 in to 1/4 in, 200 lb Load Capacity (MPN 4H24). Key specifications — Beam Flange Thickness: 1/8 in to 1/4 in; Load Capacity: 200 lb; Material: Steel; Finish: Corrosion Resistant Coated; Color: Silver; Mounting Orientation: Side Mount; Mounting Style: Hammer On; For Use With: Bolting Straps.
Beam Clip with Conduit & Pipe Hanger, Hammer-On: 1/2 in_3/4 in Trade Size, 25 lb Load Capacity (MPN BG-8-12-E-2-4). Key specifications — Compatible Conduit Trade Size: 1/2 in; 3/4 in; Compatible Conduit Type: EMT; RMC; Beam Flange Thickness: 1/8 in to 1/4 in; Material: Steel; Finish: Zinc Plated; Color: Black.
