Beckett PowerLight Oil 12 VDC Igniters
Heavy-duty 12 VDC igniter for industrial fuel oil burners. Delivers 20kV peak output for reliable startup across heating, agriculture, and food processing applications.
SKU 3G-BKT-00030
Also listed as: 51829 U · 51829-U
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
Heavy-duty 12 VDC igniter for industrial fuel oil burners. Delivers 20kV peak output for reliable startup across heating, agriculture, and food processing applications.
Frequently Asked Questions
What is the Beckett PowerLight Oil 12 VDC Igniter used for?
The Beckett PowerLight Oil 12 VDC Igniter is a heavy-duty igniter designed for industrial fuel oil burners. It delivers a 20kV peak output to ensure reliable startup in heating, agriculture, and food processing applications where a robust ignition source is required.
What are the specifications of the Beckett PowerLight Oil 12 VDC Igniter?
The Beckett PowerLight Oil 12 VDC Igniter operates on 10.8–16 VDC input with a maximum input current of 2.5 A. It provides 20kV peak output voltage and 25 mA RMS output current. Ambient operating temperature range is -40°F (-40°C) to 150°F (66°C).
Where to buy the Beckett PowerLight Oil 12 VDC Igniter in Singapore?
You can source the Beckett PowerLight Oil 12 VDC Igniter through 3G Electric in Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this heavy-duty 12 VDC igniter for industrial fuel oil burners.
How to install the Beckett PowerLight Oil 12 VDC Igniter?
Ensure the burner is disconnected from power before installation. Mount the Beckett igniter securely, connect the 10.8–16 VDC supply, and verify the 20kV peak output. Follow the manufacturer's wiring diagram and observe all safety precautions for high-voltage equipment. Test for reliable ignition after installation.
Key Features
- 20kV peak output voltage for consistent, fast ignition
- 12 VDC input with 10.8–16V operating range
- Lightweight single-piece design under 1 lb
- Universal compatibility with Beckett and other manufacturer burners
- Fully potted epoxy encapsulation resists moisture and thermal shock
- High-temperature thermoplastic housing withstands oil and chemical exposure
- Operating temperature range -40°C to 66°C
- Handles 5–95% relative humidity without performance loss
- Simplified wiring reduces installation time and complexity
- Vacuum-encapsulated construction for superior heat dissipation and insulation
- No external heat sink required, minimizing replacement frequency
- Available with or without factory-installed baseplate
