Beckett PowerLight Gas Igniters - Spare Parts
Image not available
BeckettSpare Parts

Beckett PowerLight Gas Igniters

Reliable replacement gas igniter for industrial heating systems. Beckett PowerLight delivers high-voltage spark ignition with universal compatibility across equipment brands and demanding environments.

SKU 3G-BKT-00135

Brand
Beckett
Item
PowerLight Gas Igniters
Category
Spare Parts
UNSPSC
40151728 — Pump repair kits
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Beckett
Moisture
5 to 95% Relative Humidity
Input Current
0.2A
Input Voltage
120Vac (102 Vac min. - 132Vac max.)
System Supply
Circuit protection at 20A for the system
Output Current
25mA RMS
Output Voltage
18.5kV peak
Storage Temperature
-40 to +150°F
Ambient Operating Temperature
-40 to +150°F
View Full Spec Sheet
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Beckett Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

Reliable replacement gas igniter for industrial heating systems. Beckett PowerLight delivers high-voltage spark ignition with universal compatibility across equipment brands and demanding environments.

Key Features

  • Universal replacement design compatible with Beckett and competitor igniters
  • 18.5kV peak output voltage from 120VAC input
  • Continuous duty rated for extended industrial operation
  • Single-post output configuration
  • Operates reliably from -40°F to +150°F ambient temperature
  • Tolerates 5–95% relative humidity without performance degradation
  • Low input current draw at 0.2A with 25mA RMS output
  • Standard 120VAC supply with 20A circuit protection compatibility
  • Quick installation as direct replacement unit
  • Suitable for construction, food processing, and residential heating applications

Used in

Common applications for Beckett
American-spec food-processing boiler burners — AFG scheduled-maintenance parts
Institutional kitchen and cafeteria plant — SF series for 3–7 GPH continuous duty
Commercial gas / dual-fuel — CG10 / CG15 / CG25 for medium-scale installations
Marine and offshore auxiliary plant — Beckett semi-commercial oil burners
Retrofit swap from ageing Italian burners where customer prefers American-style simpler service catalog
