BRAD HARRISON Cordset: M12 Female Right Angle X Bare Wire, 3 Pins, Yellow, PVC, 2 m Cable Lg - Single-Ended Cordsets with PVC Jacket for Flexing Applications
BRAD HARRISONSingle-Ended Cordsets with PVC Jacket for Flexing Applications

BRAD HARRISON Cordset: M12 Female Right Angle X Bare Wire, 3 Pins, Yellow, PVC, 2 m Cable Lg

The BRAD HARRISON Cordset is a single-ended cordset with PVC jacket for flexing applications, featuring an M12 female right-angle connector on end 1 and bare wire on end 2. It has 3 pins, a 2 m cable length, 22 AWG…

SKU 3G-OTH-51212

Brand
BRAD HARRISON
Item
Cordset: M12 Female Right Angle X Bare Wire, 3 Pins, Yellow, PVC, 2 m Cable Lg
Category
Single-Ended Cordsets with PVC Jacket for Flexing Applications
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

BRAD HARRISON
Manufacturer Part Number
803001A09M020
Type
Yellow, PVC
Pins
3
Cable Lg
2 m
IP Rating
IP68
Wire Size
22 AWG
NEMA Rating
6P
End 1 Gender
Female
Max Current (A)
4 A
Cable Jacket Color
Yellow
Cable Jacket Material
PVC
End 1 Connection Type
M12
End 2 Connection Type
Bare Wire
End 1 Mounting Orientation
Right Angle
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

BRAD HARRISON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The BRAD HARRISON Cordset is a single-ended cordset with PVC jacket for flexing applications, featuring an M12 female right-angle connector on end 1 and bare wire on end 2. It has 3 pins, a 2 m cable length, 22 AWG wire size, and a maximum current of 4 A. The yellow PVC jacket provides IP68 and NEMA 6P ratings.

Frequently Asked Questions

What is the BRAD HARRISON M12 cordset used for?

This single-ended cordset connects sensors and actuators in industrial automation, packaging, and material handling equipment. The M12 female right-angle connector and bare wire end simplify wiring in tight spaces. Its yellow PVC jacket with IP68 and NEMA 6P ratings suits wet or dusty environments.

What are the specifications of the BRAD HARRISON 803001A09M020 cordset?

This cordset has 3 pins, 22 AWG wire, 2 m cable length, and a 4 A max current. It features an M12 female right-angle connector on end 1 and bare wire on end 2. The yellow PVC jacket is rated IP68 and NEMA 6P for protection against dust and water immersion.

Where to buy BRAD HARRISON cordsets worldwide?

3G Electric supplies BRAD HARRISON cordsets worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your facility. Contact us for availability and lead time on the 803001A09M020 or other configurations.

How to install a BRAD HARRISON M12 cordset with bare wire?

Connect the M12 female right-angle end to the sensor or device, then terminate the bare wires into a terminal block or controller per the pinout. Ensure the cable is routed to avoid sharp bends. Tighten the M12 coupling nut by hand to maintain the IP68 seal.

Used in

Common applications for BRAD HARRISON
Factory automation — BRAD HARRISON M12 cordsets (e.g., SKU 2EPL5) connect proximity sensors to PLC I/O modules in assembly lines.
Material handling — BRAD HARRISON 7/8"-16 cordsets (SKU 5AA48) power solenoid valves on conveyor systems.
Process control — BRAD HARRISON Micro M12 receptacles (SKU 2EPG9) interface with pressure transmitters in chemical plants.
Packaging machinery — BRAD HARRISON M12 right-angle cordsets (SKU 2EPH8) connect photoelectric sensors in tight spaces.
Washdown environments — BRAD HARRISON IP68-rated cordsets (SKU 2EPN1) are used in food processing equipment requiring frequent cleaning.
Robotics — BRAD HARRISON M12 male cordsets (SKU 2ENL8) provide signal connections for end-of-arm tooling.

BRAD HARRISON Products

3G Electric supplies BRAD HARRISON single-ended cordsets with pvc jacket for flexing applications. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
