BRENNAN INDUSTRIES Compression Fitting Elbow: 1/16 in OD x 1/16 in Pipe Size, Tube x MNPT

This clean & bagged double-ferrule brass compression fitting elbow connects 1/16 in OD tubing to a 1/16 in male NPT port. It is used in instrumentation, pneumatic, and hydraulic systems where a leak-tight, vibration-resistant seal is required. BRENNAN INDUSTRIES fittings are compatible with Hy-Lok brands.

The BRENNAN INDUSTRIES N2501-01-01-B is a tube x MNPT brass compression fitting elbow in the N2501 series. It fits 1/16 in OD tube and 1/16 in pipe size. It is a clean & bagged double-ferrule design, compatible with Hy-Lok fitting brands. The manufacturer part number is N2501-01-01-B.

3G Electric supplies BRENNAN INDUSTRIES compression fittings, including the N2501-01-01-B, to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote on this or any other industrial fitting from our broad range of categories.

To install a double-ferrule compression fitting, slide the nut and ferrules onto the tube, insert the tube fully into the fitting body, then tighten the nut by hand. Use a wrench to tighten an additional 1-1/4 turns for a proper seal. Always follow the manufacturer's instructions for torque and tube preparation.
