BURNDY Upper and Lower Crimping Die: For Use With MD6/MD7/PAT600/PATMD/Y500CTHS, 4 Sizes - Burndy Replacement Crimping Dies
BURNDYBurndy Replacement Crimping Dies

BURNDY Upper and Lower Crimping Die: For Use With MD6/MD7/PAT600/PATMD/Y500CTHS, 4 Sizes

The BURNDY Upper and Lower Crimping Die (SKU 22P127, MPN WC) is a replacement crimping die set for use with MD6/MD7/PAT600/PATMD/Y500CTHS tools. It accommodates 6 to 1/0 AWG ACSR conductors and is compatible with AAC…

SKU 3G-OTH-252891

Brand
BURNDY
Item
Upper and Lower Crimping Die: For Use With MD6/MD7/PAT600/PATMD/Y500CTHS, 4 Sizes
Category
Burndy Replacement Crimping Dies
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

BURNDY
Manufacturer Part Number
WC
Type
MD6/MD7/PAT600/PATMD/Y500CTHS, 2 PK
Sizes
4
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

BURNDY Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The BURNDY Upper and Lower Crimping Die (SKU 22P127, MPN WC) is a replacement crimping die set for use with MD6/MD7/PAT600/PATMD/Y500CTHS tools. It accommodates 6 to 1/0 AWG ACSR conductors and is compatible with AAC conductors, featuring a Brown color code and YDSR-RL die type. This 2-pack includes 4 sizes.

Frequently Asked Questions

What is the BURNDY Upper and Lower Crimping Die used for?

The BURNDY Upper and Lower Crimping Die set is used to create secure, permanent crimp connections on ACSR and AAC conductors ranging from 6 to 1/0 AWG. It is designed for use with MD6, MD7, PAT600, PATMD, and Y500CTHS tools, making it essential for electrical utility and industrial power installations.

What are the specifications of the BURNDY Upper and Lower Crimping Die?

This 2-pack die set (MPN WC) accommodates 6 to 1/0 AWG ACSR conductors and is compatible with AAC conductors. It features a Brown color code, YDSR-RL die type, and is designed for use with BURNDY tools including MD6, MD7, PAT600, PATMD, and Y500CTHS. The set includes four sizes total.

Where to buy BURNDY Upper and Lower Crimping Dies worldwide?

3G Electric supplies BURNDY Upper and Lower Crimping Dies worldwide. As a global industrial equipment distributor established in 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us to source this BURNDY die set for your crimping applications.

How to select the correct BURNDY crimping die for your tool?

To select the correct BURNDY crimping die, verify your tool model (MD6, MD7, PAT600, PATMD, or Y500CTHS) and conductor type (ACSR or AAC) and size (6 to 1/0 AWG). The Brown color code and YDSR-RL die type indicate compatibility. Always match the die to the conductor material and gauge for reliable connections.
