CABLOFILBrackets for Wire Mesh Trays

CABLOFIL Universal Bracket: 20 in Wd, Steel

The CABLOFIL Universal Bracket (MPN FASUCB500PG) is a steel, galvanized bracket designed for use with Cablofil 20 in Width Mesh Tray. This bracket supports wire mesh tray installations with a 20-inch width, featuring…

SKU 3G-OTH-52526

Brand

CABLOFIL

Item

Universal Bracket: 20 in Wd, Steel

Technical Specifications

CABLOFIL

Manufacturer Part Number

FASUCB500PG

Material

Steel

Finish

Galvanized

For Use With

Cablofil 20 in Width Mesh Tray

Item [MERCH]

Universal Bracket

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

CABLOFIL Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

What is the CABLOFIL Universal Bracket used for?

The CABLOFIL Universal Bracket supports 20-inch wide wire mesh cable trays in industrial and commercial cable management systems. It provides secure mounting for tray runs, ensuring proper cable support and routing in electrical installations, data centers, and manufacturing facilities.

What are the specifications of the CABLOFIL Universal Bracket?

The CABLOFIL Universal Bracket (MPN FASUCB500PG) is made of steel with a galvanized finish for corrosion resistance. It is designed for use with Cablofil 20-inch width mesh trays. The bracket is a universal type, suitable for supporting tray installations in various environments.

Where to buy CABLOFIL Universal Bracket worldwide?

3G Electric supplies the CABLOFIL Universal Bracket worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time; we source and deliver this bracket to any location.

How to install the CABLOFIL Universal Bracket?

Install the CABLOFIL Universal Bracket by attaching it to a support structure using appropriate fasteners. Align the bracket with the 20-inch mesh tray and secure it per manufacturer guidelines. Ensure the bracket is level and properly torqued to support the cable load safely.

Used in

Common applications for CABLOFIL

Industrial manufacturing plants — CABLOFIL straight section wire mesh trays (e.g., CF105/500EZ) for routing power and control cables overhead.

Data centers — CABLOFIL wire mesh trays with universal brackets (e.g., FASUCB300PG) for structured cabling and fiber optic cable management.

Commercial building electrical rooms — CABLOFIL C brackets (e.g., FASC300PG) supporting tray runs for branch circuit wiring.

Infrastructure projects (tunnels, airports) — CABLOFIL galvanized trays and brackets for cable support in corrosive or outdoor environments.

Renewable energy installations (solar farms) — CABLOFIL wire mesh trays for DC cable routing between solar panels and inverters.

Oil and gas facilities — CABLOFIL zinc-plated or galvanized trays for cable management in hazardous area classifications.
