CALDWELL Vertical Coil Lifter: Vertical Eye Coil Lifter, 10,000 lb Max Load Capacity - Handle-Actuated Vertical Coil Lifters
CALDWELLHandle-Actuated Vertical Coil Lifters

CALDWELL Vertical Coil Lifter: Vertical Eye Coil Lifter, 10,000 lb Max Load Capacity

The CALDWELL Vertical Coil Lifter is a handle-actuated vertical eye coil lifter with a 10,000 lb max load capacity and an 8 in foot width (MPN 83E-5-16/20/24). 3G Electric sources this genuine industrial lifting…

SKU 3G-OTH-330185

Brand
CALDWELL
Item
Vertical Coil Lifter: Vertical Eye Coil Lifter, 10,000 lb Max Load Capacity
Category
Handle-Actuated Vertical Coil Lifters
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

CALDWELL
Manufacturer Part Number
83E-5-16/20/24
Foot Wd
8 in
Max Load Capacity
10,000 lb
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

CALDWELL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The CALDWELL Vertical Coil Lifter is a handle-actuated vertical eye coil lifter with a 10,000 lb max load capacity and an 8 in foot width (MPN 83E-5-16/20/24). 3G Electric sources this genuine industrial lifting solution across 14 departments, with specialist depth in material handling equipment.

Frequently Asked Questions

What is a CALDWELL Vertical Coil Lifter used for?

A CALDWELL Vertical Coil Lifter is used in steel mills, metal service centers, and manufacturing plants to safely lift and transport steel coils in a vertical orientation. The handle-actuated design allows one-person operation, reducing manual handling risk and improving productivity in heavy industrial environments.

What are the specifications of the CALDWELL 83E-5-16/20/24 coil lifter?

The CALDWELL 83E-5-16/20/24 Vertical Coil Lifter has a maximum load capacity of 10,000 lb and a foot width of 8 in. It is a handle-actuated vertical eye coil lifter designed for lifting coils by their inner diameter. Always verify compatibility with your coil dimensions before ordering.

Where to buy a CALDWELL Vertical Coil Lifter worldwide?

3G Electric supplies and delivers the CALDWELL Vertical Coil Lifter to customers worldwide. As a global industrial sourcing partner, we handle full logistics, customs clearance, and delivery to your facility. Contact us for a quote and lead time on this model.

How to select the right CALDWELL coil lifter for my application?

To select the correct CALDWELL coil lifter, match the lifter's maximum load capacity (10,000 lb for model 83E-5-16/20/24) and foot width (8 in) to your coil weight and inner diameter. Ensure the handle-actuated design suits your lifting environment. Consult the manufacturer's guidelines for safe operation and maintenance.

Used in

Common applications for CALDWELL
Manufacturing floor — CALDWELL adjustable-span gantry crane (e.g., K90-1-10/16) for moving heavy machinery components
Warehouse loading dock — CALDWELL fixed-span gantry crane (e.g., H90-1-16/20) for lifting palletized goods
Maintenance workshop — CALDWELL wall-mounted jib crane (e.g., D180-2-12) for servicing equipment in tight spaces
Construction site — CALDWELL portable gantry crane (e.g., K90-4-12/10) for hoisting building materials
Assembly line — CALDWELL base-plate mounted jib crane (e.g., A360-3-20/12) for positioning parts during production

CALDWELL Products

3G Electric supplies CALDWELL handle-actuated vertical coil lifters. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
