CANARM Exhaust Fan: 24 in Blade, 1 Speed, 1/3 hp, Totally Enclosed Air Over, 5,520 cfm - Hazardous Location Shutter-Mount Exhaust Fans
CANARMHazardous Location Shutter-Mount Exhaust Fans

CANARM Exhaust Fan: 24 in Blade, 1 Speed, 1/3 hp, Totally Enclosed Air Over, 5,520 cfm

The CANARM AX24-4M is a 24-inch hazardous location shutter-mount exhaust fan with a 1/3 hp, 1-speed motor in a totally enclosed air-over enclosure, delivering 5,520 cfm at 230/460V AC, 3-phase. Its aluminum frame and…

SKU 3G-OTH-80490

Brand
CANARM
Item
Exhaust Fan: 24 in Blade, 1 Speed, 1/3 hp, Totally Enclosed Air Over, 5,520 cfm
Category
Hazardous Location Shutter-Mount Exhaust Fans
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

CANARM
Manufacturer Part Number
AX24-4M
Type
1/3 hp, Totally Enclosed Air Over, 5,520 cfm, 3 ph
AC
230/460V
Speed
1
Frame Finish
Aluminum
Frame Material
Aluminum
Motor Enclosure
Totally Enclosed Air Over
Number of Speeds
1
Nameplate Voltage
230/460V AC
Hazardous Location Class
Class I, Div 1, Group C and D
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

CANARM Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The CANARM AX24-4M is a 24-inch hazardous location shutter-mount exhaust fan with a 1/3 hp, 1-speed motor in a totally enclosed air-over enclosure, delivering 5,520 cfm at 230/460V AC, 3-phase. Its aluminum frame and finish support Class I, Div 1, Groups C and D, and Class II, Div 1, Groups F and G locations.

Frequently Asked Questions

What is the CANARM AX24-4M exhaust fan used for?

The CANARM AX24-4M is a hazardous location shutter-mount exhaust fan designed for Class I, Div 1, Groups C and D, and Class II, Div 1, Groups F and G environments. It moves 5,520 cfm at 230/460V AC, 3-phase, making it suitable for industrial ventilation in areas with flammable gases or combustible dusts.

What are the specifications of the CANARM AX24-4M?

The CANARM AX24-4M has a 24-inch blade, 1/3 hp totally enclosed air-over motor, 1 speed, and delivers 5,520 cfm at 230/460V AC, 3-phase. It features an aluminum frame and finish, and is rated for Class I, Div 1, Groups C and D, and Class II, Div 1, Groups F and G hazardous locations.

Where to buy the CANARM AX24-4M worldwide?

3G Electric supplies the CANARM AX24-4M hazardous location exhaust fan to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this Class I/II rated fan.

How to install a CANARM AX24-4M shutter-mount exhaust fan?

Install the CANARM AX24-4M in a wall or roof opening using the provided shutter frame. Ensure the electrical supply matches the 230/460V AC, 3-phase nameplate voltage. Follow all local codes for hazardous location wiring. The totally enclosed air-over motor requires unobstructed airflow for cooling.
