CARLING TECHNOLOGIES Toggle Switch: 3 Position, 9 Connections, 3PDT - Panel-Mount Toggle Switches
CARLING TECHNOLOGIESPanel-Mount Toggle Switches

CARLING TECHNOLOGIES Toggle Switch: 3 Position, 9 Connections, 3PDT

The CARLING TECHNOLOGIES Toggle Switch is a panel-mount, 3-position switch with an On/Off/On configuration. This 3PDT model (MPN HM254-73) features 9 connections and screw terminals, rated at 10 A @ 250 V AC and 3/4…

SKU 3G-OTH-35135

Brand
CARLING TECHNOLOGIES
Item
Toggle Switch: 3 Position, 9 Connections, 3PDT
Category
Panel-Mount Toggle Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

CARLING TECHNOLOGIES
Manufacturer Part Number
HM254-73
Series
H
Type
3PDT, Screw Terminals Connection
Horsepower
3/4 hp
Connections
9
AC Contact Rating
10 A @ 250 V
Switch Function Configuration
On/Off/On
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

CARLING TECHNOLOGIES Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The CARLING TECHNOLOGIES Toggle Switch is a panel-mount, 3-position switch with an On/Off/On configuration. This 3PDT model (MPN HM254-73) features 9 connections and screw terminals, rated at 10 A @ 250 V AC and 3/4 hp. It belongs to the Series H line.

Frequently Asked Questions

What is the CARLING TECHNOLOGIES HM254-73 toggle switch used for?

The CARLING TECHNOLOGIES HM254-73 is a panel-mount 3PDT toggle switch used for industrial control circuits, motor switching, and equipment power management. Its On/Off/On configuration and 10 A @ 250 V AC rating suit applications in machining, material handling, and HVAC systems.

What are the specifications of the CARLING TECHNOLOGIES HM254-73 toggle switch?

The HM254-73 is a 3-position, 3PDT toggle switch with 9 screw-terminal connections. It has an AC contact rating of 10 A @ 250 V and a horsepower rating of 3/4 hp. It belongs to the CARLING TECHNOLOGIES Series H line and is designed for panel mounting.

Where to buy the CARLING TECHNOLOGIES HM254-73 toggle switch worldwide?

3G Electric supplies the CARLING TECHNOLOGIES HM254-73 toggle switch to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for a quote and lead time on this Series H switch.

How to install a CARLING TECHNOLOGIES panel-mount toggle switch?

To install a CARLING TECHNOLOGIES panel-mount toggle switch, cut a standard panel hole, insert the switch, and secure it with the mounting nut. Connect wires to the screw terminals per your circuit diagram, ensuring the On/Off/On function matches your control logic. Always de-energize circuits before installation.

Used in

Common applications for CARLING TECHNOLOGIES
Industrial control panels — Carling Technologies F Series toggle switches for On/Off/On control of motors and pumps
Marine electrical systems — Carling Technologies 700 series rotary switches for selecting battery banks or generator modes
Off-highway vehicle dashboards — Carling Technologies R135 series rotary switches for headlight or wiper control
HVAC equipment — Carling Technologies 170 series miniature push buttons for momentary fan or compressor activation
Generator sets — Carling Technologies 6FA58-73 toggle switch for manual start/stop with momentary off function
Material handling machinery — Carling Technologies 110-SP maintained push button for emergency stop or latch-on control
