What is the maintenance schedule for the Delta Pump AD1 R2?

We recommend a full seal kit replacement every 500-1000 operating hours depending on application. Oil changes should be performed every 250 hours. Contact our service team for a customized maintenance plan.

DeltaOil Pumps

Delta Pump AD1 R2

Delta Pump AD1 R2 is an oil pump for industrial hydraulic systems, delivering up to 3500 rpm with a pressure setting of 10 ±0.3 bar. Features a stainless steel mesh strainer rated 130µ and operates on 230 VAC 50/60Hz…

SKU 3G-CBM-01890

Also listed as: DEL 03404 · DEL-03404

Brand

Delta

Item

Pump AD1 R2

Technical Specifications

Delta

strainer

Stainless steel mesh 130µ, 11cm²

nozzle port

G1/8

cable length

700 mm

hub diameter

Ø32 mm

standard coil

230 VAC 50/60Hz

rotation speed

3500 rpm max

shaft diameter

Ø8 mm

solenoid power

9 W

pressure setting

10 ±0.3 bar

ambient temperature

0°C / 60°C

inlet return connection

G1/4

View Full Spec Sheet

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Delta Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Used in

Common applications for Delta

Oil burner heating systems — Delta VM1 and VM2 fuel unit pumps delivering 35–55 l/h at 20 bar pressure setting

Industrial lubrication circuits — Delta A-series and A2-series pumps with 130 µm stainless steel strainers at 10 bar pressure

Hydraulic equipment integration — Delta AD-series pumps rated 3500 rpm with 32 mm hub diameter for modular system assembly

Burner nozzle supply — Delta fuel units with G1/8" nozzle port and solenoid valve integration for atomization control

Replacement pump specification — Delta cable assemblies (700 mm, 3-core) for retrofit and maintenance of existing burner equipment

Multi-stage heating plant operation — Delta VM2 models with 150 µm nylon filtration for continuous-duty burner fuel supply
