Econex 24V AC servo motor AB1A1002SE5 90° 15sec 4-20mA
Econex AB1A1002SE5 is a 24V AC servo motor for heating system applications, delivering 90° rotation in 15 seconds with 4-20mA control. IP54-rated with ISO 5211 F07 fastening, it operates across -10 to +60°C for HVAC…
SKU 3G-CBM-02569
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
Econex AB1A1002SE5 is a 24V AC servo motor for heating system applications, delivering 90° rotation in 15 seconds with 4-20mA control. IP54-rated with ISO 5211 F07 fastening, it operates across -10 to +60°C for HVAC valve actuation and damper control.
Frequently Asked Questions
What is the Econex AB1A1002SE5 servo motor used for?
The Econex AB1A1002SE5 is a 24V AC servo motor designed for heating system applications, including modulating valves, butterfly valves, dampers, and other fluid regulation systems requiring 90° angular positioning.
What are the specifications of the Econex AB1A1002SE5?
The Econex AB1A1002SE5 is a 24V AC servo motor with 4-20mA control, 90° rotation in 15 seconds, IP54 enclosure, ISO 5211 F07 fastening, 10mm output shaft, and operates from -10 to +60°C. It delivers 3 to 5 Nm nominal torque.
Where to buy the Econex AB1A1002SE5 in Singapore?
3G Electric supplies the Econex AB1A1002SE5 servo motor to Singapore. We handle logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this HVAC valve actuator.
How to install the Econex AB1A1002SE5 servo motor?
Install the Econex AB1A1002SE5 in any position using the ISO 5211 F07 fastening pattern. Ensure the 24V AC supply and 4-20mA control signal are correctly wired per the diagram. Adjust rotation angle via the friction cams. Always disconnect power before installation.
