Fantini Cosmi Adjusting pressure switch B12ENY 8-28 bar
Fantini Cosmi B12ENY is an adjusting pressure switch with G 1/4 flange connection for fluid systems requiring precise pressure monitoring from 8–28 bar. Features 2–6 bar differential and IP40 protection, suitable for…
SKU 3G-CBM-03565
Local availability & support — Singapore
- Local office
- 20 Woodlands Link #09-05, Singapore 738733
- Phone
- +65 8878 8355
- Delivery
- Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
- Payment
- Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
- Ships to
- Singapore
Need installation or engineering help?
Ask a question
Product Description
Fantini Cosmi B12ENY is an adjusting pressure switch with G 1/4 flange connection for fluid systems requiring precise pressure monitoring from 8–28 bar. Features 2–6 bar differential and IP40 protection, suitable for industrial hydraulic and pneumatic applications operating to 120°C.
Frequently Asked Questions
What is the Fantini Cosmi B12ENY pressure switch used for?
The Fantini Cosmi B12ENY is an adjustable pressure switch for monitoring and regulating fluids and non-explosive gases in industrial systems. Typical applications include compression plants, boilers, tanks, autoclaves, ventilation plants, and lubrication plants. It is suitable for hydraulic and pneumatic circuits requiring precise pressure control from 8 to 28 bar.
What are the specifications of the Fantini Cosmi B12ENY?
The B12ENY has a pressure range of 8–28 bar with an adjustable differential of 2–6 bar. It features a G 1/4 flange connection, IP65 waterproof casing, and a sensitive element rated to 32 bar. Maximum fluid temperature is 120 °C, with a body temperature range of –35 to 60 °C. The SPDT microswitch is rated for 16 A continuous current.
Where to buy the Fantini Cosmi B12ENY in Singapore?
3G Electric supplies the Fantini Cosmi B12ENY adjusting pressure switch to Singapore. We handle sourcing, logistics, customs clearance, and local delivery for industrial customers. Contact our team for pricing and lead time on this SKU 3G-CBM-03565. We provide technical support for selection and application.
How to install the Fantini Cosmi B12ENY pressure switch?
Install the B12ENY directly on the pipe using the G 1/4 flange connection. For fluid temperatures above 120 °C, insert a metallic spiral between the switch and pipe to dissipate heat. The switch can be mounted on a 35 mm metallic clamp (except waterproof versions). Ensure wiring follows the SPDT microswitch diagram for correct operation.
