Fantini Cosmi Probe for thermostat/hygrostat LS150

Fantini Cosmi LS150 thermocouple J probe for thermostat and hygrostat applications measures temperature from 0 to 450°C with ±2.5°C precision. Features stainless steel AISI 316 construction, IP65 protection, 160 mm…

SKU 3G-CBM-03663

Also listed as: FAN 24060 · FAN-24060

Brand

Fantini Cosmi

Item

Probe for thermostat/hygrostat LS150

Local availability & support — Singapore

Local office: 20 Woodlands Link #09-05, Singapore 738733
Phone: +65 8878 8355
Delivery: Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
Payment: Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
Ships to: Singapore

Technical Specifications

Fantini Cosmi

type

LS150 thermocouple J probe

material

steel AISI 316

precision

±2.5°C

conductors

2x0.5 mm²

protection

IP65

tip length mm

160

cable length cm

300

tip diameter mm

6

temperature range

0 to 450°C

Datasheet Content

FAN24054 à 62
                          Sonde LS pour thermostats et hygrostat.




         LS120-LS123               LS130                     LS140                     LS150                          LS160A
         (PTC1000)                 (NTC10K)                  (PT100)                   (termocoup.J)                  (UR%)




SONDE POUR THERMOSTAT
Type                  Temp.      Precision                 Tip           Protection    Conductors                Cable
                      range                                               degree                        temperature    lenght
                       °C           °K                     mm                              mm²              °C           cm
LS120 (PTC1000)      -40 ÷105   ± 1,5 a 25°C              Ø 6x34           IP67            2x0,4         -40 ÷ 105        200 cm
LS123 (PTC1000)      -40 ÷105   ± 1,5 a 25°C              Ø 6x34           IP67       2x0,4 + display    -40 ÷ 105        200 cm
LS140 (PT100)        0 ÷ 400    ± 0,3 a 0°C     Ø 6x160 steel AISI 316     IP65            3x0,2          0 ÷ 400         100 cm
LS150 (termocoup.J) 0 ÷ 450        ±2,5         Ø 6x160 steel AISI 316     IP65            2x0,5          0 ÷ 450         300 cm
LS130 (NTC10K)       -40 ÷105   ± 1,5 a 25°C              Ø 6x34           IP67            2x0,4         -40 ÷ 105        200 cm




SONDE POUR HYGROSTAT
Type                  UR%                       UR%                        Dimensons                        Protection
                      range                   Precision                                                      degree
                                                                               mm
LS160A               0 ÷100%             <± 0,7 (0÷100%UR)                 110 x 75 x 53                       IP65

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Fantini Cosmi Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

What is the Fantini Cosmi LS150 probe used for?

The Fantini Cosmi LS150 thermocouple J probe measures temperature from 0 to 450°C for thermostat and hygrostat applications. It is designed for HVAC and industrial control systems requiring precise temperature monitoring in demanding environments.

What are the specifications of the Fantini Cosmi LS150 probe?

The LS150 probe features a stainless steel AISI 316 construction, IP65 protection, 160 mm tip length, 6 mm tip diameter, and 300 cm cable with 2x0.5 mm² conductors. It offers ±2.5°C precision over a 0 to 450°C temperature range.

Where to buy the Fantini Cosmi LS150 probe in Singapore?

3G Electric supplies the Fantini Cosmi LS150 probe to Singapore. We handle logistics, customs clearance, and delivery for industrial procurement. Contact us to source this probe for your HVAC or control system needs.

How to install the Fantini Cosmi LS150 probe?

Install the LS150 probe by inserting the 160 mm tip into the measurement point, ensuring the AISI 316 sheath withstands up to 450°C. Route the 300 cm cable away from electrical noise and secure with IP65-rated fittings for reliable thermostat or hygrostat operation.
