Preciman Green ABS pressure gauge D63 0/+1bar G1/4

Preciman green ABS pressure gauge measures low-pressure systems with 63 mm face diameter and ±2.5% accuracy. Features G1/4 connection and 0 to +1 bar range, ideal for pneumatic and light industrial applications.

SKU 3G-CBM-06299

Also listed as: ROS 28004 · ROS-28004

Brand

Preciman

Item

Green ABS pressure gauge D63 0/+1bar G1/4

Part Number

ROS28004

Local availability & support — Singapore

Local office: 20 Woodlands Link #09-05, Singapore 738733
Phone: +65 8878 8355
Delivery: Same-day or next-business-day delivery within Singapore for in-stock items; 7–14 days for factory-order parts from Europe.
Payment: Invoicing in SGD. PayNow, bank transfer, and corporate PO accepted.
Ships to: Singapore

Technical Specifications

Preciman

size

2.5" (63mm)

accuracy

±2.5%

connection

G1/4

case material

green ABS

pressure range

0 to +1 bar

Datasheet Content

ROS27002 à 35034



Pressure Gauge
Black ABS Case (Snap in acrylic)
Application
Used for pneumatic systems compressors, regulator
and industry machine suitable for fluid medium or
gaseous which does not clog connection port or corrode
copper alloy.
Specification
Size: 1.5"(40mm), 2"(50mm), 2.5"(63mm)
      3"(75mm), "(100mm)
Acceracy: ±2.5% of full scales for 1.5"(40mm)
           ±1.6% of full scales for 2"(50mm),2.5"(63mm)
           3"(75mm),4"(100mm)
Range available: -30"Hg~0 (vacuum)
                 -30"Hg~0~6000psi (compound)
                 0~15psi~6000psi (pressure)
Housing: Black ABS case
Window: Snap in acrylic
Bourdon tube: Copper-alloy
Movement: Semi-copper alloy
Connection: Brass
Pointer and dial: Aluminum
Thread: 1/8"BSP(NPT), 1/4"BSP(NPT), 1/2"BSP(NPT)
Operating temperature: -20 °C ~ 60 °C (-4 °F ~ 140 °F)
Working pressure: Steady: 3/4 of full scale
                  Fluctuating: 2/3 of full scale
                  Short time: full scale

Technical Documents

(1)

Technical Document 1

PDF Document

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

Preciman Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

What is the Preciman Green ABS pressure gauge D63 0/+1bar G1/4 used for?

The Preciman Green ABS pressure gauge is used for measuring low-pressure systems in pneumatic applications, compressors, regulators, and industrial machinery. It is suitable for fluid or gaseous media that do not clog the connection port or corrode copper alloy components.

What are the specifications of the Preciman Green ABS pressure gauge D63?

The Preciman Green ABS pressure gauge has a 63 mm (2.5") face diameter, ±2.5% accuracy, G1/4 connection, green ABS case, and a pressure range of 0 to +1 bar. It features a copper-alloy Bourdon tube and operates between -20 °C and 60 °C.

Where to buy the Preciman Green ABS pressure gauge in Singapore?

You can source the Preciman Green ABS pressure gauge through 3G Electric in Singapore. We handle logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this item.

How to install the Preciman Green ABS pressure gauge?

Install the Preciman Green ABS pressure gauge by applying thread sealant to the G1/4 connection and tightening it into a compatible port. Avoid over-torquing. For steady pressure, do not exceed 3/4 of full scale; for fluctuating pressure, limit to 2/3 of full scale.

Used in

Common applications for Preciman

Boiler steam-system monitoring — Preciman D100 glycerin gauges (0–40 bar) mounted on boiler headers and steam-outlet lines.

Pump discharge pressure indication — Preciman D63 axial stainless gauges (0–250 bar) on centrifugal-pump outlet manifolds and pressure-relief test points.

Compressed-air and vacuum systems — Preciman vacuum and low-range gauges (−1 to +0 bar, 0–1.6 bar) on air-treatment equipment and vacuum pumps.

Hydraulic-circuit monitoring — Preciman all-stainless manometers (D63 vertical, up to 250 bar) on hydraulic-press and industrial-lifting-system manifolds.

Fuel-gas and burner control lines — Preciman D63 low-range gauges (0–1 bar, 0–2.5 bar) on natural-gas and LPG regulator outlet monitoring.

Heat-exchanger and thermal-loop diagnostics — Preciman glycerin D63/D100 gauges for hot-water circulation and process-steam secondary loops.
