CHAINFLEX Control Cable: 18 AWG, 12 Conductors, 25 ft, PUR Jacket - Continuous Flexing Control Cables
CHAINFLEXContinuous Flexing Control Cables

CHAINFLEX Control Cable: 18 AWG, 12 Conductors, 25 ft, PUR Jacket

The CHAINFLEX Control Cable (SKU 24A998, MPN CF77-UL-07-12-25) is a continuous flexing control cable from the Chainflex CF77-UL series. This 25-foot cable features 18 AWG, 12 copper conductors with a PUR jacket…

SKU 3G-OTH-47840

Brand
CHAINFLEX
Item
Control Cable: 18 AWG, 12 Conductors, 25 ft, PUR Jacket
Category
Continuous Flexing Control Cables
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

CHAINFLEX
Manufacturer Part Number
CF77-UL-07-12-25
Series
Chainflex
Standards
CE
Cable Series
CF77-UL
Product Type
Control Cable
Includes Ground
Yes
Conductor Material
Copper
Conductor Color Code
Black with White Numbers
Resistance Properties
Flame Retardant
Conductor Configuration
Single
Minimum Bend Radius Factor - Fixed
4 x OD
Minimum Bend Radius Factor - E-Chain
6.8 x OD
Minimum Bend Radius Factor - Flexible
5 x OD
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

CHAINFLEX Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The CHAINFLEX Control Cable (SKU 24A998, MPN CF77-UL-07-12-25) is a continuous flexing control cable from the Chainflex CF77-UL series. This 25-foot cable features 18 AWG, 12 copper conductors with a PUR jacket, rated at 1,000 V, and includes a ground conductor. It is flame retardant, CE certified, and designed for fixed, flexible, and e-chain applications with minimum bend radius factors of 4 x OD, 5 x OD, and 6.8 x OD respectively.

Frequently Asked Questions

What is CHAINFLEX Control Cable used for?

The CHAINFLEX CF77-UL control cable is designed for continuous flexing applications in industrial automation, robotics, and cable carriers (e-chain). It transmits control signals and power in machinery requiring repeated bending, with a PUR jacket for durability and flame retardance.

What are the specifications of CHAINFLEX Control Cable CF77-UL-07-12-25?

This cable has 12 conductors of 18 AWG copper, rated at 1,000 V, with a PUR jacket. It includes a ground conductor and is CE certified. Minimum bend radius factors are 4 x OD for fixed, 5 x OD for flexible, and 6.8 x OD for e-chain applications.

Where to buy CHAINFLEX Control Cable in worldwide?

3G Electric supplies and delivers the CHAINFLEX CF77-UL-07-12-25 control cable worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to ensure reliable delivery to your facility, regardless of location.

How to select the right CHAINFLEX control cable for e-chain?

Select based on conductor count, AWG, voltage rating, and bend radius. For e-chain use, ensure the cable's minimum bend radius factor (6.8 x OD for this model) matches your application. Verify jacket material (PUR for abrasion resistance) and certifications like CE for compliance.

Used in

Common applications for CHAINFLEX
Automated assembly lines — Chainflex CF10 control cables for signal transmission in cable carriers
Robotic arms — Chainflex CF280ULH servo motor cables for power and feedback in high-flex joints
Material handling conveyors — Chainflex CF78-UL control cables with PUR jacket for oil resistance
CNC machining centers — Chainflex CF9-UL control cables rated at 1,000 V for spindle and axis control
Packaging machinery — Chainflex CFBUS-PVC-021 bus cables for CAN-Bus communication in continuous motion
Automotive manufacturing — Chainflex CF2 control cables with UV-resistant PUR jacket for outdoor gantry systems
