CHAINFLEX Control Cable: 20 AWG, 7 Conductors, 25 ft, PVC Jacket - Continuous Flexing Control Cables
CHAINFLEXContinuous Flexing Control Cables

CHAINFLEX Control Cable: 20 AWG, 7 Conductors, 25 ft, PVC Jacket

The CHAINFLEX CF6-05-07-25 is a continuous flexing control cable from the Chainflex series, featuring 20 AWG, 7 conductors, a PVC jacket, and a 600 V rating. It includes a ground conductor, is made of copper with a…

SKU 3G-OTH-46406

Brand
CHAINFLEX
Item
Control Cable: 20 AWG, 7 Conductors, 25 ft, PVC Jacket
Category
Continuous Flexing Control Cables
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

CHAINFLEX
Manufacturer Part Number
CF6-05-07-25
Series
Chainflex
Standards
CE
Cable Series
CF6
Product Type
Control Cable
Includes Ground
Yes
Conductor Material
Copper
Conductor Color Code
Black with White Numbers
Resistance Properties
Heat Resistant
Conductor Configuration
Single
Minimum Bend Radius Factor - Fixed
4 x OD
Minimum Bend Radius Factor - E-Chain
6.8 x OD
Minimum Bend Radius Factor - Flexible
5 x OD
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

CHAINFLEX Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The CHAINFLEX CF6-05-07-25 is a continuous flexing control cable from the Chainflex series, featuring 20 AWG, 7 conductors, a PVC jacket, and a 600 V rating. It includes a ground conductor, is made of copper with a single conductor configuration, and is heat resistant. The cable meets CE standards and has minimum bend radius factors of 4 x OD for fixed installation, 5 x OD for flexible use, and 6.8 x OD for e-chain applications.

Frequently Asked Questions

What is the CHAINFLEX CF6-05-07-25 control cable used for?

The CHAINFLEX CF6-05-07-25 is a continuous flexing control cable designed for automated machinery, robotics, and cable carrier (e-chain) applications. Its 20 AWG, 7-conductor construction with a PVC jacket and 600 V rating suits dynamic bending environments where reliable signal or low-power transmission is required.

What are the specifications of the CHAINFLEX CF6-05-07-25?

This CHAINFLEX cable has 20 AWG, 7 conductors, a PVC jacket, and a 600 V rating. It includes a ground conductor, uses single copper conductors, and is heat resistant. Minimum bend radius factors are 4 x OD fixed, 5 x OD flexible, and 6.8 x OD for e-chain. It meets CE standards.

Where to buy the CHAINFLEX CF6-05-07-25 worldwide?

3G Electric supplies the CHAINFLEX CF6-05-07-25 control cable worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time; we source and deliver this cable to any international destination.

How to select the right CHAINFLEX continuous flex cable?

Select a CHAINFLEX cable based on conductor count, AWG size, voltage rating, and jacket material for your application. For e-chain use, ensure the minimum bend radius factor (e.g., 6.8 x OD for CF6-05-07-25) matches your carrier. Always verify CE compliance and heat resistance requirements for your environment.

Used in

Common applications for CHAINFLEX
Automated assembly lines — Chainflex CF10 control cables for signal transmission in cable carriers
Robotic arms — Chainflex CF280ULH servo motor cables for power and feedback in high-flex joints
Material handling conveyors — Chainflex CF78-UL control cables with PUR jacket for oil resistance
CNC machining centers — Chainflex CF9-UL control cables rated at 1,000 V for spindle and axis control
Packaging machinery — Chainflex CFBUS-PVC-021 bus cables for CAN-Bus communication in continuous motion
Automotive manufacturing — Chainflex CF2 control cables with UV-resistant PUR jacket for outdoor gantry systems
