CHAINFLEX Control Cable: 14 AWG Conductor Size, 4 Conductors, PVC, 100 ft - Continuous Flexing Exposed Run Tray Cables
CHAINFLEXContinuous Flexing Exposed Run Tray Cables

CHAINFLEX Control Cable: 14 AWG Conductor Size, 4 Conductors, PVC, 100 ft

The CHAINFLEX Control Cable (MPN CF130US-25-04-100) is a continuous flexing exposed run tray cable with 14 AWG conductor size, 4 conductors, PVC jacket, 100 ft length, and gray color. It is unshielded and has a…

SKU 3G-OTH-45939

Brand
CHAINFLEX
Item
Control Cable: 14 AWG Conductor Size, 4 Conductors, PVC, 100 ft
Category
Continuous Flexing Exposed Run Tray Cables
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

CHAINFLEX
Manufacturer Part Number
CF130US-25-04-100
Shielding
Unshielded
Conductor Size
14 AWG
Minimum Bend Radius Factor - Fixed
5 x OD
Minimum Bend Radius Factor - Flexible
7.5 x OD
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

CHAINFLEX Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The CHAINFLEX Control Cable (MPN CF130US-25-04-100) is a continuous flexing exposed run tray cable with 14 AWG conductor size, 4 conductors, PVC jacket, 100 ft length, and gray color. It is unshielded and has a minimum bend radius factor of 5 x OD for fixed installations and 7.5 x OD for flexible applications.

Frequently Asked Questions

What is the CHAINFLEX Control Cable used for?

The CHAINFLEX Control Cable is designed for continuous flexing exposed run tray applications. It is commonly used in automated machinery, robotics, and conveyor systems where cables must withstand repeated bending and movement in cable carriers or cable trays.

What are the specifications of the CHAINFLEX Control Cable CF130US-25-04-100?

This CHAINFLEX cable has a 14 AWG conductor size, 4 conductors, PVC jacket, and is 100 ft long with a gray color. It is unshielded, with a minimum bend radius factor of 5 x OD for fixed installations and 7.5 x OD for flexible applications.

Where to buy CHAINFLEX Control Cable worldwide?

3G Electric supplies the CHAINFLEX Control Cable worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this cable.

How to select the right CHAINFLEX Control Cable for continuous flexing?

Select based on conductor size, number of conductors, and bend radius requirements. For continuous flexing, ensure the cable's flexible bend radius factor (7.5 x OD for this CHAINFLEX model) matches your application's cable carrier or tray path to avoid premature failure.

Used in

Common applications for CHAINFLEX
Automated assembly lines — Chainflex CF10 control cables for signal transmission in cable carriers
Robotic arms — Chainflex CF280ULH servo motor cables for power and feedback in high-flex joints
Material handling conveyors — Chainflex CF78-UL control cables with PUR jacket for oil resistance
CNC machining centers — Chainflex CF9-UL control cables rated at 1,000 V for spindle and axis control
Packaging machinery — Chainflex CFBUS-PVC-021 bus cables for CAN-Bus communication in continuous motion
Automotive manufacturing — Chainflex CF2 control cables with UV-resistant PUR jacket for outdoor gantry systems
