CHIEF Hydraulic Directional Control Valve: Four-Way / Three Positions - Stack Valve Working Sections
CHIEFStack Valve Working Sections

CHIEF Hydraulic Directional Control Valve: Four-Way / Three Positions

The CHIEF Hydraulic Directional Control Valve is a four-way, three-position stack valve working section with a manual actuation mechanism and detent spool action. It features #10 SAE O-Ring Boss work connections and…

SKU 3G-OTH-169256

Brand
CHIEF
Item
Hydraulic Directional Control Valve: Four-Way / Three Positions
Category
Stack Valve Working Sections
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

CHIEF
Manufacturer Part Number
220853
Type
21 gpm Flow Rate - Max
Spool Action
Detent
Port Connections
Work
Actuation Mechanism
Manual
Work Connection Size
#10
Work Connection Type
SAE O-Ring Boss
Pressure Connection Size
#10
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

CHIEF Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The CHIEF Hydraulic Directional Control Valve is a four-way, three-position stack valve working section with a manual actuation mechanism and detent spool action. It features #10 SAE O-Ring Boss work connections and a #10 pressure connection, with a maximum flow rate of 21 gpm. This valve is designed for hydraulic systems requiring directional control of fluid flow.

Frequently Asked Questions

What is the CHIEF Hydraulic Directional Control Valve used for?

The CHIEF Hydraulic Directional Control Valve is used in hydraulic systems to control the direction of fluid flow. It is a four-way, three-position stack valve working section, ideal for applications requiring precise directional control, such as mobile equipment, agricultural machinery, and industrial hydraulic circuits.

What are the specifications of the CHIEF Hydraulic Directional Control Valve?

The CHIEF Hydraulic Directional Control Valve (MPN 220853) has a maximum flow rate of 21 gpm, manual actuation, detent spool action, and #10 SAE O-Ring Boss work connections with a #10 pressure connection. It is a four-way, three-position stack valve working section designed for hydraulic directional control.

Where to buy the CHIEF Hydraulic Directional Control Valve worldwide?

You can source the CHIEF Hydraulic Directional Control Valve worldwide through 3G Electric. As a global industrial equipment distributor, 3G Electric handles full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this valve.

How to install a CHIEF Hydraulic Directional Control Valve?

Install the CHIEF Hydraulic Directional Control Valve by mounting it in a stack configuration with compatible sections. Ensure all connections are tightened to SAE O-Ring Boss specifications. Use clean hydraulic fluid and follow standard practices for directional control valves to avoid leaks and ensure proper spool detent operation.

Used in

Common applications for CHIEF
Agricultural equipment — CHIEF welded cylinders (e.g., 2 in bore, 42 in stroke) for tractor implements and loaders
Construction machinery — CHIEF clevis-mount welded cylinders (e.g., 3 in bore, 30 in stroke) for excavator attachments
Material handling — CHIEF tie-rod cylinders (e.g., 3 1/2 in bore, 12 in stroke) for forklift mast actuation
Mobile hydraulics — CHIEF DC power units (1.2 gpm, 2,800 psi) for dump truck hoists and spreader systems
Industrial automation — CHIEF rephasing tie-rod cylinders for synchronized press or clamp operations
Waste management — CHIEF welded cylinders (e.g., 4 in bore, 32 in stroke) for compactor and baler applications

CHIEF Products

3G Electric supplies CHIEF stack valve working sections. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
