COMPX TIMBERLINE Cabinet and Drawer Lock Cylinder: Keyed Different, 1/2 in Cylinder Dia
The COMPX TIMBERLINE Cabinet and Drawer Lock Cylinder (SKU 5ELH2) is a keyed-different cylinder for cabinet and drawer locks, featuring a 1/2 in cylinder diameter in a Satin Nickel finish. This model, with…
SKU 3G-OTH-420570
Need installation or engineering help?
Ask a question
Product Description
The COMPX TIMBERLINE Cabinet and Drawer Lock Cylinder (SKU 5ELH2) is a keyed-different cylinder for cabinet and drawer locks, featuring a 1/2 in cylinder diameter in a Satin Nickel finish. This model, with manufacturer part number C700LP-KD-15, includes the 200T specification and is designed for use with COMPX TIMBERLINE locking systems.
Frequently Asked Questions
What is the COMPX TIMBERLINE Cabinet and Drawer Lock Cylinder used for?
This keyed-different cylinder is used to secure cabinets and drawers in commercial furniture, lockers, and storage units. It replaces or upgrades existing COMPX TIMBERLINE locking systems, providing a satin nickel finish and a 1/2 in cylinder diameter for standard panel thicknesses.
What are the specifications of the COMPX TIMBERLINE C700LP-KD-15 cylinder?
The COMPX TIMBERLINE C700LP-KD-15 cylinder has a 1/2 in cylinder diameter, satin nickel finish, and is keyed different. It includes the 200T specification and is designed for cabinet and drawer locks. The manufacturer part number is C700LP-KD-15, and it is made by COMPX TIMBERLINE.
Where to buy COMPX TIMBERLINE cabinet lock cylinders worldwide?
3G Electric supplies COMPX TIMBERLINE cabinet and drawer lock cylinders worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us to source the C700LP-KD-15 or similar models for your project.
How to install a COMPX TIMBERLINE cabinet lock cylinder?
To install, remove the existing lock cylinder and insert the COMPX TIMBERLINE C700LP-KD-15 into the mounting hole. Secure it with the retaining clip or screw, then test the key operation. Ensure the cam aligns with the drawer or door strike. Refer to the manufacturer's instructions for torque specs.
