CRYDOM Solid State Relay: Surface Mounted, 50 A Max Output Current, SCR - Surface-Mounted Relays
CRYDOMSurface-Mounted Relays

CRYDOM Solid State Relay: Surface Mounted, 50 A Max Output Current, SCR

The CRYDOM D53TP50D-10 is a panel-mounted, surface-mounted solid-state relay with a DC input current of 35 mA and an AC output voltage range of 48 to 530V AC. It features a Form A switch configuration, SCR output…

SKU 3G-OTH-38278

Brand
CRYDOM
Item
Solid State Relay: Surface Mounted, 50 A Max Output Current, SCR
Category
Surface-Mounted Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

CRYDOM
Manufacturer Part Number
D53TP50D-10
Type
SCR, AC Output
Finger Safe
Yes
Current Type
DC
Input Current
35 mA
Mounting Style
Panel
Output Voltage
48 to 530V AC
Max Output Current
50 A
Switch Configuration
Form A
Voltage/Current Type
AC Output
Electrical Connection
Saddle Clamp
Maximum Output Current without Heat Sink
Not Recommended
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

CRYDOM Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The CRYDOM D53TP50D-10 is a panel-mounted, surface-mounted solid-state relay with a DC input current of 35 mA and an AC output voltage range of 48 to 530V AC. It features a Form A switch configuration, SCR output, and a saddle-clamp electrical connection, with a maximum output current of 50 A (operation without a heat sink is not recommended). This finger-safe relay is designed for AC output applications.

Frequently Asked Questions

What is the CRYDOM D53TP50D-10 solid state relay used for?

The CRYDOM D53TP50D-10 is a panel-mounted solid state relay for AC output applications. It switches AC loads up to 50 A and 530V AC, making it suitable for industrial heating, motor control, and lighting systems where silent, reliable switching is required.

What are the specifications of the CRYDOM D53TP50D-10?

The CRYDOM D53TP50D-10 has a DC input current of 35 mA, AC output voltage range of 48 to 530V AC, and maximum output current of 50 A. It features a Form A switch configuration, SCR output, saddle-clamp electrical connection, and is finger safe. Operation without a heat sink is not recommended.

Where to buy the CRYDOM D53TP50D-10 worldwide?

You can source the CRYDOM D53TP50D-10 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the CRYDOM D53TP50D-10 solid state relay?

Mount the CRYDOM D53TP50D-10 on a panel using the saddle-clamp and screw connections. Ensure proper heat sinking as operation without a heat sink is not recommended. Follow standard electrical safety practices and torque specifications for terminal connections.
