CRYDOM Solid State Relay: DIN-Rail Mounted, 30 A Max Output Current, SCR - DIN-Rail Mounted Relays
CRYDOMDIN-Rail Mounted Relays

CRYDOM Solid State Relay: DIN-Rail Mounted, 30 A Max Output Current, SCR

The CRYDOM Solid State Relay is a DIN-Rail Mounted relay with a Form A switch configuration and SCR output. It handles AC output voltages from 48 to 530V AC and a maximum output current of 30 A without a heat sink…

SKU 3G-OTH-36847

Brand
CRYDOM
Item
Solid State Relay: DIN-Rail Mounted, 30 A Max Output Current, SCR
Category
DIN-Rail Mounted Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

CRYDOM
Manufacturer Part Number
CKRA4830
Type
SCR, AC Output
Finger Safe
Yes
Current Type
AC
Input Current
5 mA
Mounting Style
DIN Rail
Output Voltage
48 to 530V AC
Max Output Current
30 A
Switch Configuration
Form A
Voltage/Current Type
AC Output
Electrical Connection
Screw Clamp
Maximum Output Current without Heat Sink
30 A
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

CRYDOM Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The CRYDOM Solid State Relay is a DIN-Rail Mounted relay with a Form A switch configuration and SCR output. It handles AC output voltages from 48 to 530V AC and a maximum output current of 30 A without a heat sink. The relay features a 5 mA input current, screw clamp electrical connection, and is finger safe.

Used in

Common applications for CRYDOM
Industrial burner control — CRYDOM CL240A10C SSR for modulating gas valve actuation
Pump motor switching — CRYDOM C53TP25CH-10 SSR for single-phase AC motor start/stop
Process heating — CRYDOM EL240A10R-05 SSR for electric heater bank control
DIN-rail thermal management — CRYDOM HS151DR heat sink with fan for SSR cooling in control panels
Three-phase load switching — CRYDOM CD2450W2V dual SSR for two-phase control in industrial ovens

CRYDOM Products

3G Electric supplies CRYDOM din-rail mounted relays. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
