Dayton Exhaust Fan: Direct Drive, 16 in Blade, 1/20 hp, 1,334 cfm, 115V AC, 1 ph - Standard Direct-Drive Panel Exhaust Fans
DaytonStandard Direct-Drive Panel Exhaust Fans

Dayton Exhaust Fan: Direct Drive, 16 in Blade, 1/20 hp, 1,334 cfm, 115V AC, 1 ph

The Dayton 10D956 is a standard direct-drive panel exhaust fan with a 16-inch blade, 1/20 hp motor, and 1,334 cfm airflow at 115V AC single phase. It features a galvanized steel frame, stamped construction, and a…

SKU 3G-OTH-80488

Brand
Dayton
Item
Exhaust Fan: Direct Drive, 16 in Blade, 1/20 hp, 1,334 cfm, 115V AC, 1 ph
Category
Standard Direct-Drive Panel Exhaust Fans
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
10D956
Type
1/20 hp, 1,334 cfm, 1 ph, Totally Enclosed
AC
115V
Blade
16 in
Assembled
Assembled
Guard Type
Intake
Frame Finish
Galvanized
Frame Material
Steel
Motor Enclosure
Totally Enclosed Air Over
Enclosure Design
Totally Enclosed Motor
Motor Insulation
Class B
Number of Speeds
1
Nameplate Voltage
115V AC
Guard Type Subheads
With Intake Guards
Method of Construction
Stamped
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton 10D956 is a standard direct-drive panel exhaust fan with a 16-inch blade, 1/20 hp motor, and 1,334 cfm airflow at 115V AC single phase. It features a galvanized steel frame, stamped construction, and a totally enclosed air-over motor with Class B insulation. The unit is assembled and includes intake guards.

Frequently Asked Questions

What is the Dayton 10D956 exhaust fan used for?

The Dayton 10D956 is a standard direct-drive panel exhaust fan designed for general ventilation in industrial and commercial spaces. It moves 1,334 cfm at 115V AC, making it suitable for removing heat, fumes, or stale air from workshops, warehouses, and plant areas.

What are the specifications of the Dayton 10D956 exhaust fan?

The Dayton 10D956 has a 16-inch blade, 1/20 hp motor, 1,334 cfm airflow, and 115V AC single-phase power. It features a galvanized steel frame, stamped construction, totally enclosed air-over motor with Class B insulation, and includes intake guards. The unit is assembled.

Where to buy the Dayton 10D956 exhaust fan worldwide?

You can source the Dayton 10D956 exhaust fan through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this model.

How to install the Dayton 10D956 direct-drive exhaust fan?

Mount the Dayton 10D956 securely in a panel opening using the provided intake guards. Ensure the 115V AC power supply matches the nameplate rating. Use a dedicated circuit with proper overcurrent protection. Follow local electrical codes and the manufacturer's manual for safe installation.

Used in

Common applications for Dayton
HVAC ventilation — DAYTON centrifugal upblast roof exhaust fans (SKU 7M7U3) for kitchen exhaust systems
Mechanical power transmission — DAYTON HTD timing pulleys (SKU 404GV0) for conveyor belt drives
Process water handling — DAYTON self-priming centrifugal pumps (SKU 2ZXT4) for dewatering or transfer
Roofing and building services — DAYTON fixed ventilated roof curbs (SKU 4HX59) for filtered supply fan installations
Material handling — DAYTON latch assemblies (SKU 2KEN4) for electric chain hoist hook safety
Industrial air movement — DAYTON downblast roof exhaust fans (SKU 3HFL9) for clean air exhaust in manufacturing plants

Dayton Products

3G Electric supplies Dayton standard direct-drive panel exhaust fans. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
