Dayton Ring Exhaust Fan: 30 in Blade, 3/4 hp, Totally Enclosed Fan Cooled, 115/208-230V AC - Hazardous Location Ring Exhaust Fans
DaytonHazardous Location Ring Exhaust Fans

Dayton Ring Exhaust Fan: 30 in Blade, 3/4 hp, Totally Enclosed Fan Cooled, 115/208-230V AC

The DAYTON Ring Exhaust Fan (SKU 10E020) is a hazardous location ring exhaust fan with a 30-inch blade. It features a 3/4 hp, Totally Enclosed Fan Cooled motor and operates at 115/208-230V AC, delivering 8,153 cfm on…

SKU 3G-OTH-80120

Brand
Dayton
Item
Ring Exhaust Fan: 30 in Blade, 3/4 hp, Totally Enclosed Fan Cooled, 115/208-230V AC
Category
Hazardous Location Ring Exhaust Fans
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
10E020
Type
3/4 hp, Totally Enclosed Fan Cooled, 8,153 cfm, 1 ph
AC
115/208-230V
Motor Enclosure
Totally Enclosed Fan Cooled
Nameplate Voltage
115/208-230V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Ring Exhaust Fan (SKU 10E020) is a hazardous location ring exhaust fan with a 30-inch blade. It features a 3/4 hp, Totally Enclosed Fan Cooled motor and operates at 115/208-230V AC, delivering 8,153 cfm on single-phase power.

Frequently Asked Questions

What is the DAYTON Ring Exhaust Fan 10E020 used for?

The DAYTON Ring Exhaust Fan 10E020 is a hazardous location ring exhaust fan designed for ventilating areas with potentially flammable or explosive atmospheres. It moves 8,153 cfm of air using a 30-inch blade, making it suitable for industrial plants, warehouses, and processing facilities requiring explosion-proof ventilation.

What are the specifications of the DAYTON Ring Exhaust Fan 10E020?

The DAYTON Ring Exhaust Fan 10E020 has a 30-inch blade, a 3/4 hp Totally Enclosed Fan Cooled motor, and operates on 115/208-230V AC single-phase power. It delivers 8,153 cfm airflow. The motor enclosure is TEFC, suitable for hazardous locations. The manufacturer part number is 10E020.

Where to buy the DAYTON Ring Exhaust Fan 10E020 worldwide?

You can source the DAYTON Ring Exhaust Fan 10E020 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide competitive pricing and reliable sourcing for this DAYTON fan.

How to install the DAYTON Ring Exhaust Fan 10E020?

Install the DAYTON Ring Exhaust Fan 10E020 by mounting it securely in a wall or roof opening, ensuring proper support for its weight. Connect the 115/208-230V AC single-phase power to the TEFC motor per local electrical codes. Use appropriate conduit and seal fittings for hazardous locations. Always follow the manufacturer's manual for safe installation.
