Dayton Attic Exhaust Fan: Gable Mount, Electric Motor, Max. 1,900 sq ft Attic - Gable-Mount Attic Exhaust Fans
DaytonGable-Mount Attic Exhaust Fans

Dayton Attic Exhaust Fan: Gable Mount, Electric Motor, Max. 1,900 sq ft Attic

The Dayton 10W196 is a gable-mount attic exhaust fan with a standard-efficiency electric motor. It operates at 120V AC and 3 A, delivering a maximum airflow of 1,320 cfm for attics up to 1,900 sq ft. The unit…

SKU 3G-OTH-78646

Brand
Dayton
Item
Attic Exhaust Fan: Gable Mount, Electric Motor, Max. 1,900 sq ft Attic
Category
Gable-Mount Attic Exhaust Fans
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
10W196
Type
Electric Motor, Max. 1,900 sq ft Attic, Thermostat
Max.
1,320 cfm
Current
3 A
Features
Temperature Control
Includes
Thermostat
Dome Material
Plastic
Includes Shutter
No
Mounting Location
Gable
Nameplate Voltage
120V AC
Includes Humidistat
No
Includes Thermostat
Yes
Fire Safety Shut-Off
No
High-Efficiency Motor
No
Power Source/High-Efficiency Motors
Standard-Efficiency Motor
Exhaust Airflow @ 0.000 in SP - Range
1,000 to 1,499 cfm
For High-Static Pressure Applications
No
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton 10W196 is a gable-mount attic exhaust fan with a standard-efficiency electric motor. It operates at 120V AC and 3 A, delivering a maximum airflow of 1,320 cfm for attics up to 1,900 sq ft. The unit includes a thermostat for temperature control and features a plastic dome, but does not include a shutter, humidistat, or fire safety shut-off.

Frequently Asked Questions

What is the Dayton 10W196 attic exhaust fan used for?

The Dayton 10W196 is a gable-mount attic exhaust fan designed to ventilate attics up to 1,900 sq ft. It removes hot, stale air to reduce heat buildup and moisture, helping protect roofing and insulation. The included thermostat enables automatic temperature-based operation.

What are the specifications of the Dayton 10W196 gable-mount fan?

The Dayton 10W196 operates at 120V AC and 3 A, delivering a maximum airflow of 1,320 cfm. It includes a thermostat for temperature control, has a plastic dome, and uses a standard-efficiency electric motor. It does not include a shutter, humidistat, or fire safety shut-off.

Where to buy the Dayton 10W196 attic exhaust fan worldwide?

3G Electric supplies the Dayton 10W196 gable-mount attic exhaust fan to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this model.

How to install a Dayton gable-mount attic exhaust fan?

Install the Dayton 10W196 in a gable opening, ensuring the fan is securely mounted and wired to a 120V AC supply. Connect the included thermostat for automatic temperature control. Follow local electrical codes and ensure proper attic ventilation for optimal performance.
