Dayton Shaft Collar: 1-Piece, Set Screw, 7/16 in Bore Dia, 7/8 in Collar Outside Dia - Stainless Steel Shaft Collars
DaytonStainless Steel Shaft Collars

Dayton Shaft Collar: 1-Piece, Set Screw, 7/16 in Bore Dia, 7/8 in Collar Outside Dia

The DAYTON Shaft Collar (SKU 1L635) is a 1-piece stainless steel shaft collar with a set screw locking mechanism. It features a 7/16 in bore diameter and a 7/8 in collar outside diameter. This industrial component is…

SKU 3G-OTH-186966

Brand
Dayton
Item
Shaft Collar: 1-Piece, Set Screw, 7/16 in Bore Dia, 7/8 in Collar Outside Dia
Category
Stainless Steel Shaft Collars
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
1L635
Type
Set Screw
EA
1
Bore Dia
7/16 in
Collar Outside Dia
7/8 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Shaft Collar (SKU 1L635) is a 1-piece stainless steel shaft collar with a set screw locking mechanism. It features a 7/16 in bore diameter and a 7/8 in collar outside diameter. This industrial component is designed for securing components onto a shaft.

Frequently Asked Questions

What is a DAYTON Shaft Collar used for?

A DAYTON Shaft Collar secures components like bearings, sprockets, or pulleys onto a shaft, preventing axial movement. It is commonly used in industrial machinery, conveyors, and power transmission systems to maintain precise positioning and reduce wear.

What are the specifications of the DAYTON Shaft Collar 1L635?

The DAYTON Shaft Collar 1L635 is a 1-piece stainless steel set screw type with a 7/16 in bore diameter and a 7/8 in collar outside diameter. It is sold individually (EA 1) and is designed for reliable shaft component retention.

Where to buy a DAYTON Shaft Collar worldwide?

3G Electric supplies the DAYTON Shaft Collar 1L635 to customers worldwide. We handle full logistics, customs clearance, and delivery, ensuring you receive the correct industrial component for your application, regardless of location.

How to install a set screw shaft collar?

To install a set screw shaft collar, slide it onto the shaft to the desired position, then tighten the set screw against the shaft using a hex key. Ensure the screw is torqued to manufacturer recommendations to prevent slippage under load.
