Dayton Shaft Collar: 1-Piece, Set Screw, 1 in Bore Dia, 1 5/8 in Collar Outside Dia - Stainless Steel Shaft Collars
DaytonStainless Steel Shaft Collars

Dayton Shaft Collar: 1-Piece, Set Screw, 1 in Bore Dia, 1 5/8 in Collar Outside Dia

The DAYTON Shaft Collar (MPN 1L640) is a 1-piece stainless steel shaft collar with a set screw locking mechanism. It features a 1 in bore diameter and a 1 5/8 in collar outside diameter. This industrial component is…

SKU 3G-OTH-186982

Brand
Dayton
Item
Shaft Collar: 1-Piece, Set Screw, 1 in Bore Dia, 1 5/8 in Collar Outside Dia
Category
Stainless Steel Shaft Collars
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
1L640
Type
Set Screw
EA
1
Bore Dia
1 in
Collar Outside Dia
1 5/8 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Shaft Collar (MPN 1L640) is a 1-piece stainless steel shaft collar with a set screw locking mechanism. It features a 1 in bore diameter and a 1 5/8 in collar outside diameter. This industrial component is designed for securing components onto shafts.

Frequently Asked Questions

What is the DAYTON Shaft Collar 1L640 used for?

The DAYTON Shaft Collar 1L640 is used to secure components such as pulleys, gears, or bearings onto a shaft. Its set screw locking mechanism provides a firm grip, preventing axial movement in industrial machinery, conveyors, and power transmission systems.

What are the specifications of the DAYTON Shaft Collar 1L640?

The DAYTON Shaft Collar 1L640 is a 1-piece stainless steel collar with a set screw lock. It has a 1 in bore diameter and a 1 5/8 in collar outside diameter. The manufacturer part number is 1L640, and it is sold individually (1 EA).

Where to buy the DAYTON Shaft Collar 1L640 worldwide?

You can source the DAYTON Shaft Collar 1L640 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring the component reaches your facility reliably.

How to install a set screw shaft collar like the DAYTON 1L640?

To install the DAYTON 1L640, slide the collar onto the shaft at the desired position. Tighten the set screw using a hex key until it contacts the shaft firmly. Avoid overtightening to prevent shaft damage. Always verify alignment before finalizing the lock.
