Dayton Shaft Collar: 1-Piece, Set Screw, 1 3/16 in Bore Dia, 2 in Collar Outside Dia - Stainless Steel Shaft Collars
DaytonStainless Steel Shaft Collars

Dayton Shaft Collar: 1-Piece, Set Screw, 1 3/16 in Bore Dia, 2 in Collar Outside Dia

The DAYTON Shaft Collar (SKU 1L642) is a 1-piece stainless steel shaft collar with a set screw locking mechanism. It features a 1 3/16 in bore diameter and a 2 in collar outside diameter. This product is manufactured…

SKU 3G-OTH-186987

Brand
Dayton
Item
Shaft Collar: 1-Piece, Set Screw, 1 3/16 in Bore Dia, 2 in Collar Outside Dia
Category
Stainless Steel Shaft Collars
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
1L642
Type
Set Screw
EA
1
Bore Dia
1 3/16 in
Collar Outside Dia
2 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Shaft Collar (SKU 1L642) is a 1-piece stainless steel shaft collar with a set screw locking mechanism. It features a 1 3/16 in bore diameter and a 2 in collar outside diameter. This product is manufactured by Dayton under part number 1L642.

Frequently Asked Questions

What is the DAYTON Shaft Collar 1L642 used for?

The DAYTON Shaft Collar 1L642 is used to secure components on a shaft, preventing axial movement in industrial machinery. It is commonly applied in conveyor systems, gearboxes, and power transmission assemblies where precise positioning and reliable locking are required.

What are the specifications of the DAYTON Shaft Collar 1L642?

The DAYTON Shaft Collar 1L642 is a 1-piece stainless steel collar with a set screw locking mechanism. It has a bore diameter of 1 3/16 in and a collar outside diameter of 2 in. The manufacturer part number is 1L642, and it is sold individually.

Where to buy the DAYTON Shaft Collar 1L642 worldwide?

You can source the DAYTON Shaft Collar 1L642 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring the product reaches your facility efficiently.

How to install the DAYTON Shaft Collar 1L642?

To install the DAYTON Shaft Collar 1L642, slide it onto the shaft at the desired position. Tighten the set screw using a hex key until it securely contacts the shaft. Ensure the collar is perpendicular to the shaft for even clamping force. Avoid overtightening to prevent damage.
