Dayton Shaft Collar: 1-Piece, Inch, Round, Clamp-On, 3/16 in Bore Dia - Steel Shaft Collars
DaytonSteel Shaft Collars

Dayton Shaft Collar: 1-Piece, Inch, Round, Clamp-On, 3/16 in Bore Dia

The DAYTON Shaft Collar (MPN 1L655) is a 1-piece, round, clamp-on steel shaft collar with an inch bore diameter of 3/16 in and a collar outside diameter of 5/8 in. This product is designed for industrial applications…

SKU 3G-OTH-148023

Brand
Dayton
Item
Shaft Collar: 1-Piece, Inch, Round, Clamp-On, 3/16 in Bore Dia
Category
Steel Shaft Collars
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
1L655
Type
Inch, Round, Clamp-On
Bore Dia
3/16 in
Collar Outside Dia
5/8 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Shaft Collar (MPN 1L655) is a 1-piece, round, clamp-on steel shaft collar with an inch bore diameter of 3/16 in and a collar outside diameter of 5/8 in. This product is designed for industrial applications requiring secure shaft positioning.

Frequently Asked Questions

What is the DAYTON Shaft Collar 1L655 used for?

The DAYTON Shaft Collar 1L655 is used for secure shaft positioning in industrial machinery. It clamps onto a 3/16-inch shaft to prevent axial movement, making it suitable for conveyors, motors, and power transmission systems where precise component alignment is required.

What are the specifications of the DAYTON Shaft Collar 1L655?

The DAYTON Shaft Collar 1L655 is a 1-piece, round, clamp-on steel collar. It has a 3/16-inch bore diameter and a 5/8-inch outside diameter. The inch-system design ensures compatibility with fractional-inch shafts in industrial equipment.

Where to buy the DAYTON Shaft Collar 1L655 worldwide?

3G Electric supplies the DAYTON Shaft Collar 1L655 worldwide. As a global industrial distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this steel shaft collar.

How to install a DAYTON Shaft Collar 1L655?

To install the DAYTON Shaft Collar 1L655, slide it onto a clean 3/16-inch shaft, position it at the desired location, and tighten the clamp screw evenly with a hex key. Ensure the collar is perpendicular to the shaft to avoid misalignment. Use thread-locking compound on the screw for vibration resistance.
