Dayton Gearmotor: Right Angle, Dual Output Shafts, PSC, TENV, 1.5 RPM - Right Angle AC Gearmotors
DaytonRight Angle AC Gearmotors

Dayton Gearmotor: Right Angle, Dual Output Shafts, PSC, TENV, 1.5 RPM

The DAYTON AC Gearmotor: Right Angle (SKU 1LPZ3) is a right-angle AC gearmotor with dual output shafts, a PSC motor, and TENV enclosure. It delivers 1.5 RPM and 250 in-lb max torque, with a full load current of…

SKU 3G-OTH-116185

Brand
Dayton
Item
Gearmotor: Right Angle, Dual Output Shafts, PSC, TENV, 1.5 RPM
Category
Right Angle AC Gearmotors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
1LPZ3
Type
Dual Output Shafts, PSC, TENV, 1.5 RPM, 250 in-lb Max Torque
Inverter Rated
No
Full Load Current
1.2/0.63 A
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON AC Gearmotor: Right Angle (SKU 1LPZ3) is a right-angle AC gearmotor with dual output shafts, a PSC motor, and TENV enclosure. It delivers 1.5 RPM and 250 in-lb max torque, with a full load current of 1.2/0.63 A and is not inverter rated.

Frequently Asked Questions

What is the DAYTON AC Gearmotor 1LPZ3 used for?

The DAYTON AC Gearmotor 1LPZ3 is a right-angle gearmotor with dual output shafts, ideal for low-speed, high-torque industrial applications such as conveyors, packaging machinery, and material handling equipment. Its PSC motor and TENV enclosure suit continuous-duty operation in clean, dry environments.

What are the specifications of the DAYTON AC Gearmotor 1LPZ3?

The DAYTON AC Gearmotor 1LPZ3 delivers 1.5 RPM with 250 in-lb max torque. It features a PSC motor, TENV enclosure, dual output shafts, and a full load current of 1.2/0.63 A. It is not inverter rated. The manufacturer part number is 1LPZ3.

Where to buy the DAYTON AC Gearmotor 1LPZ3 worldwide?

You can source the DAYTON AC Gearmotor 1LPZ3 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide competitive sourcing for this DAYTON gearmotor.

How to select the right DAYTON AC Gearmotor for an application?

To select the right DAYTON AC Gearmotor, match the required output speed and torque to the load. For the 1LPZ3, verify that 1.5 RPM and 250 in-lb max torque meet your needs. Ensure the motor voltage and enclosure (TENV) suit the environment. Consult a DAYTON catalog or 3G Electric for guidance.
