Dayton Gearmotor: Right Angle, 90V DC, TENV, 10 RPM, 228 in-lb Max Torque, 161:1 - Right Angle DC Gearmotors
DaytonRight Angle DC Gearmotors

Dayton Gearmotor: Right Angle, 90V DC, TENV, 10 RPM, 228 in-lb Max Torque, 161:1

The DAYTON DC Gearmotor: Right Angle is a permanent magnet DC gearmotor with a right-angle configuration. It operates at 90V DC, 10 RPM, and delivers a maximum torque of 228 in-lb with a 161:1 gear ratio. The motor…

SKU 3G-OTH-116262

Brand
Dayton
Item
Gearmotor: Right Angle, 90V DC, TENV, 10 RPM, 228 in-lb Max Torque, 161:1
Category
Right Angle DC Gearmotors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
1LRB1
Type
TENV, 10 RPM, 228 in-lb Max Torque, 0.59 A, CW/CCW
DC
90V
Motor Type
Permanent Magnet DC
Full Load Current
0.59 A
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON DC Gearmotor: Right Angle is a permanent magnet DC gearmotor with a right-angle configuration. It operates at 90V DC, 10 RPM, and delivers a maximum torque of 228 in-lb with a 161:1 gear ratio. The motor is TENV (Totally Enclosed Non-Ventilated), has a full load current of 0.59 A, and is reversible (CW/CCW).
