Dayton Double Diaphragm Pump: 316 Stainless Steel, 1 in, Tri-Clamp, 32 gpm - FDA-Compliant AODD Pumps
DaytonFDA-Compliant AODD Pumps

Dayton Double Diaphragm Pump: 316 Stainless Steel, 1 in, Tri-Clamp, 32 gpm

The DAYTON Double Diaphragm Pump (SKU 22A604) is an FDA-Compliant AODD pump constructed with 316 Stainless Steel. It features a 1-inch Tri-Clamp connection, delivers 32 gpm, and achieves a maximum head of 231 ft. The…

SKU 3G-OTH-86252

Brand
Dayton
Item
Double Diaphragm Pump: 316 Stainless Steel, 1 in, Tri-Clamp, 32 gpm
Category
FDA-Compliant AODD Pumps
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
22A604
Type
1 in, Tri-Clamp, 32 gpm
Max. Head
231 ft
Seat Material
316 SS
Check Valve Material
PTFE
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Double Diaphragm Pump (SKU 22A604) is an FDA-Compliant AODD pump constructed with 316 Stainless Steel. It features a 1-inch Tri-Clamp connection, delivers 32 gpm, and achieves a maximum head of 231 ft. The pump includes PTFE check valves and 316 SS seat material.

Frequently Asked Questions

What is the DAYTON Double Diaphragm Pump used for?

The DAYTON Double Diaphragm Pump (22A604) is an FDA-compliant AODD pump designed for sanitary transfer of fluids in food, dairy, beverage, and pharmaceutical applications. Its 316 stainless steel construction and PTFE check valves meet strict hygiene standards.

What are the specifications of the DAYTON Double Diaphragm Pump?

The DAYTON pump (MPN 22A604) features a 1-inch Tri-Clamp connection, delivers 32 gpm, and achieves a maximum head of 231 ft. It is constructed with 316 stainless steel, with PTFE check valves and 316 SS seat material.

Where to buy the DAYTON Double Diaphragm Pump worldwide?

3G Electric supplies the DAYTON Double Diaphragm Pump (22A604) worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to select the right DAYTON Double Diaphragm Pump?

Select the DAYTON pump (22A604) based on your fluid type, required flow rate (32 gpm), and head pressure (231 ft max). For sanitary applications, the 316 SS body and PTFE valves ensure FDA compliance. Confirm Tri-Clamp compatibility with your piping system.
