Dayton Gearmotor: Parallel, 90V DC, TENV, 13 RPM, 660 in-lb Max Torque - Parallel Shaft DC Gearmotors
DaytonParallel Shaft DC Gearmotors

Dayton Gearmotor: Parallel, 90V DC, TENV, 13 RPM, 660 in-lb Max Torque

The DAYTON DC Gearmotor: Parallel (SKU 2H590) is a parallel shaft DC gearmotor from the brand DAYTON. It features a Permanent Magnet DC motor type, operates at 90V DC, and has a full load current of 1.7 A. The unit…

SKU 3G-OTH-120542

Brand
Dayton
Item
Gearmotor: Parallel, 90V DC, TENV, 13 RPM, 660 in-lb Max Torque
Category
Parallel Shaft DC Gearmotors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
2H590
Type
TENV, 13 RPM, 660 in-lb Max Torque
DC
90V
Motor Type
Permanent Magnet DC
Input Horsepower
1/6 hp
Full Load Current
1.7 A
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON DC Gearmotor: Parallel (SKU 2H590) is a parallel shaft DC gearmotor from the brand DAYTON. It features a Permanent Magnet DC motor type, operates at 90V DC, and has a full load current of 1.7 A. The unit delivers 13 RPM with a maximum torque of 660 in-lb and an input horsepower of 1/6 hp, enclosed in a TENV (Totally Enclosed Non-Ventilated) housing.

Frequently Asked Questions

What is the DAYTON DC Gearmotor 2H590 used for?

The DAYTON DC Gearmotor 2H590 is used in industrial automation, conveyor systems, and material handling equipment requiring precise low-speed torque. Its parallel shaft design and 13 RPM output make it suitable for applications like indexing drives, packaging machinery, and adjustable-speed positioning where a permanent magnet DC motor with 660 in-lb maximum torque is needed.

What are the specifications of the DAYTON DC Gearmotor 2H590?

The DAYTON DC Gearmotor 2H590 is a parallel shaft permanent magnet DC motor rated at 90V DC, 1/6 hp input horsepower, and 1.7 A full load current. It delivers 13 RPM with 660 in-lb maximum torque in a TENV (Totally Enclosed Non-Ventilated) enclosure. The manufacturer part number is 2H590.

Where to buy the DAYTON DC Gearmotor 2H590 worldwide?

You can source the DAYTON DC Gearmotor 2H590 through 3G Electric, a global industrial equipment distributor established in 1990. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine DAYTON components for industrial applications.

How to select the right DAYTON DC Gearmotor for an application?

To select the right DAYTON DC Gearmotor, match the required output speed and torque to the load. For the 2H590 model, verify your system voltage is 90V DC and that the 660 in-lb maximum torque and 13 RPM meet your drive requirements. Ensure the TENV enclosure suits your environment. Consult a DAYTON application guide for duty-cycle and mounting considerations.
