Dayton Electric Plenum Heater: 15kW, 480V AC, 850/1000 CFM, 17-7/8 in x 35-3/8 in x 18 in - General Purpose Electric Plenum Heaters
DaytonGeneral Purpose Electric Plenum Heaters

Dayton Electric Plenum Heater: 15kW, 480V AC, 850/1000 CFM, 17-7/8 in x 35-3/8 in x 18 in

The DAYTON Electric Plenum Heater (SKU 2HCZ9) is a 15kW general-purpose electric plenum heater designed for 480V AC, three-phase operation. It supports an air flow of 850/1000 CFM and measures 17-7/8 in x 35-3/8 in x…

SKU 3G-OTH-63508

Brand
Dayton
Item
Electric Plenum Heater: 15kW, 480V AC, 850/1000 CFM, 17-7/8 in x 35-3/8 in x 18 in
Category
General Purpose Electric Plenum Heaters
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
2HCZ9
Type
850/1000 CFM, 17-7/8 in x 35-3/8 in x 18 in
AC
480V
Phase
3
Voltage
480V AC
Air Flow
850/1000 CFM
Wattage Output
15kW
Overall Dimensions - H x W x D
17-7/8 in x 35-3/8 in x 18 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Electric Plenum Heater (SKU 2HCZ9) is a 15kW general-purpose electric plenum heater designed for 480V AC, three-phase operation. It supports an air flow of 850/1000 CFM and measures 17-7/8 in x 35-3/8 in x 18 in (H x W x D).

Frequently Asked Questions

What is the DAYTON Electric Plenum Heater 2HCZ9 used for?

The DAYTON Electric Plenum Heater 2HCZ9 is a general-purpose electric plenum heater used for supplemental or primary heating in commercial and industrial HVAC systems. It is designed for ducted air-handling applications where 15kW, 480V AC three-phase power is available, providing 850/1000 CFM airflow.

What are the specifications of the DAYTON Electric Plenum Heater 2HCZ9?

The DAYTON Electric Plenum Heater 2HCZ9 has a wattage output of 15kW, operates on 480V AC three-phase power, and delivers an airflow of 850/1000 CFM. Its overall dimensions are 17-7/8 in x 35-3/8 in x 18 in (H x W x D). The manufacturer part number is 2HCZ9.

Where to buy the DAYTON Electric Plenum Heater 2HCZ9 worldwide?

You can source the DAYTON Electric Plenum Heater 2HCZ9 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply this unit to procurement teams and plant engineers internationally.

How to install the DAYTON Electric Plenum Heater 2HCZ9?

Install the DAYTON Electric Plenum Heater 2HCZ9 in a duct system with proper clearance for airflow and electrical connections. Ensure the power supply matches the 480V AC three-phase rating. Follow local electrical codes and the manufacturer's wiring diagram. Use a qualified electrician for safe installation and verify airflow direction before startup.
