Dayton 9.75"H-W 5"L GStl Volume Control Dampr: 5 in L, 9 3/4 in H, 9 3/4 in W - Rectangular Manual Control Dampers
DaytonRectangular Manual Control Dampers

Dayton 9.75"H-W 5"L GStl Volume Control Dampr: 5 in L, 9 3/4 in H, 9 3/4 in W

The Dayton 2LRY6 is a rectangular manual control damper with a V-groove blade and TPE blade seal, designed for ceiling mounting. It measures 9.75 inches in height and width with a 5-inch length, and includes an…

SKU 3G-OTH-74343

Brand
Dayton
Item
9.75"H-W 5"L GStl Volume Control Dampr: 5 in L, 9 3/4 in H, 9 3/4 in W
Category
Rectangular Manual Control Dampers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
2LRY6
Type
9 3/4 in W, Hat Channel, Single
H
9 3/4 in
Includes
Extension Pin Kit
Blade Type
V-Groove
Switch Action
Normally Open
Mounting Location
Ceiling
Blade Seal Material
TPE
Maximum Air Velocity
3000 fpm
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton 2LRY6 is a rectangular manual control damper with a V-groove blade and TPE blade seal, designed for ceiling mounting. It measures 9.75 inches in height and width with a 5-inch length, and includes an extension pin kit. The damper has a maximum air velocity of 3000 fpm and features a normally open switch action.

Frequently Asked Questions

What is the Dayton 2LRY6 rectangular manual control damper used for?

The Dayton 2LRY6 is used to regulate airflow in HVAC ductwork, typically in ceiling-mounted commercial or industrial ventilation systems. Its V-groove blade and TPE seal provide reliable shutoff and balancing in rectangular ducts.

What are the specifications of the Dayton 2LRY6 damper?

The Dayton 2LRY6 is a 9 3/4 in H by 9 3/4 in W rectangular manual control damper with a 5 in length. It features a V-groove blade, TPE blade seal, ceiling mounting, normally open switch action, and maximum air velocity of 3000 fpm. Includes extension pin kit.

Where to buy the Dayton 2LRY6 damper worldwide?

3G Electric supplies the Dayton 2LRY6 rectangular manual control damper to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to install a Dayton 2LRY6 ceiling-mounted damper?

Install the Dayton 2LRY6 by securing the damper frame to ceiling duct supports using the included extension pin kit. Ensure the V-groove blade moves freely and the TPE seal contacts the duct walls. Follow standard HVAC damper installation practices for rectangular ducts.
