Dayton Selector Switch: 22 mm Panel Mounting Size, 3 Positions, Extended Lever - Selector Switches
DaytonSelector Switches

Dayton Selector Switch: 22 mm Panel Mounting Size, 3 Positions, Extended Lever

The DAYTON 30G274 is a 22 mm panel-mount selector switch with a three-position, maintained action (On/Off/On) and a long-handled plastic knob. It is non-illuminated with a non-metallic bezel and is rated 10 A at 600…

SKU 3G-OTH-35484

Brand
Dayton
Item
Selector Switch: 22 mm Panel Mounting Size, 3 Positions, Extended Lever
Category
Selector Switches
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
30G274
Type
Extended Lever, 2NO, Non-Metallic
Cam
No Cam Included
Action
Maintained/Maintained/Maintained
Positions
3
AC Contact Rating
10 A @ 600 V
DC Contact Rating
2.5 A @ 600 V
Operator Head Type
Long-Handled Knob
Operator Illumination
Non-Illuminated
Operator Head Material
Plastic
Switch Bezel Material Type
Non-Metallic
Switch Function @ 1st Position
On
Switch Function @ 2nd Position
Off
Switch Function @ 3rd Position
On
Switch Function @ 4th Position
No Fourth Position
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON 30G274 is a 22 mm panel-mount selector switch with a three-position, maintained action (On/Off/On) and a long-handled plastic knob. It is non-illuminated with a non-metallic bezel and is rated 10 A at 600 V AC and 2.5 A at 600 V DC. This switch has no cam included and offers no fourth position.

Frequently Asked Questions

What is the DAYTON 30G274 selector switch used for?

The DAYTON 30G274 is a 22 mm panel-mount selector switch used for industrial control circuits, such as machine on/off selection or mode switching. Its three-position maintained action (On/Off/On) suits applications requiring stable state retention without constant operator pressure.

What are the specifications of the DAYTON 30G274 selector switch?

The DAYTON 30G274 is a 22 mm panel-mount selector switch with 3 positions, maintained action, and a long-handled plastic knob. It is rated 10 A at 600 V AC and 2.5 A at 600 V DC. It has 2NO contacts, no cam included, and a non-metallic bezel. It is non-illuminated.

Where to buy the DAYTON 30G274 selector switch worldwide?

You can source the DAYTON 30G274 selector switch through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide competitive pricing and reliable sourcing.

How to install a DAYTON 30G274 selector switch?

To install the DAYTON 30G274, mount it in a 22 mm panel cutout, secure with the provided nut, and wire the 2NO contacts according to your control circuit. Ensure power is off during installation. Use appropriate torque on terminals and verify maintained action positions (On/Off/On) before energizing.
