Dayton 44.75"H-W Alu Universal Backdraft Dampr: For 42 in Fan, Single Panel, 44 3/4 in H - Universal-Mount Backdraft Dampers
DaytonUniversal-Mount Backdraft Dampers

Dayton 44.75"H-W Alu Universal Backdraft Dampr: For 42 in Fan, Single Panel, 44 3/4 in H

The Dayton 3HHT2 is a universal-mount backdraft damper designed for horizontal airflow and horizontal mounting. It features a single-panel aluminum construction with felt seals, measuring 44.75 inches in both height…

SKU 3G-OTH-74743

Brand
Dayton
Item
44.75"H-W Alu Universal Backdraft Dampr: For 42 in Fan, Single Panel, 44 3/4 in H
Category
Universal-Mount Backdraft Dampers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
3HHT2
Type
Single Panel, 44 3/4 in W, Felt
H
44 3/4 in
Airflow Direction
Horizontal
Mounting Position
Horizontal
Maximum Air Velocity
2250 fpm
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Dayton 3HHT2 is a universal-mount backdraft damper designed for horizontal airflow and horizontal mounting. It features a single-panel aluminum construction with felt seals, measuring 44.75 inches in both height and width, and is intended for use with a 42-inch fan. The damper supports a maximum air velocity of 2250 fpm.

Frequently Asked Questions

What is the Dayton 3HHT2 backdraft damper used for?

The Dayton 3HHT2 is a universal-mount backdraft damper that prevents reverse airflow in horizontal ventilation systems. It is designed for use with a 42-inch fan, allowing air to flow in one direction while closing automatically when the fan stops, protecting equipment and maintaining system efficiency.

What are the specifications of the Dayton 3HHT2 damper?

The Dayton 3HHT2 is a single-panel aluminum backdraft damper with felt seals, measuring 44 3/4 inches in both height and width. It is designed for horizontal mounting and horizontal airflow, with a maximum air velocity of 2250 fpm. The manufacturer part number is 3HHT2.

Where to buy the Dayton 3HHT2 damper worldwide?

3G Electric supplies the Dayton 3HHT2 backdraft damper to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this and other Dayton ventilation components.

How to install the Dayton 3HHT2 backdraft damper?

Install the Dayton 3HHT2 damper in a horizontal duct section with the airflow arrow pointing away from the fan. Ensure the damper frame is securely mounted and the felt seals are intact for proper closure. Follow standard HVAC practices for duct connections and verify free movement of the single panel before operation.
