Dayton Timing Pulley: Curvilinear, Fixed, For 15 mm Belt Wd, 15 Teeth, 5 mm Pitch - HTD Section Fixed-Bore Timing Pulleys with Hub
DaytonHTD Section Fixed-Bore Timing Pulleys with Hub

Dayton Timing Pulley: Curvilinear, Fixed, For 15 mm Belt Wd, 15 Teeth, 5 mm Pitch

The DAYTON Timing Pulley is a curvilinear, HTD section fixed-bore timing pulley with hub, designed for the Powerhouse® belt series. It features a clear anodized finish, accommodates a 15 mm belt width, and has 15…

SKU 3G-OTH-104078

Brand
Dayton
Item
Timing Pulley: Curvilinear, Fixed, For 15 mm Belt Wd, 15 Teeth, 5 mm Pitch
Category
HTD Section Fixed-Bore Timing Pulleys with Hub
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
15-5M15-6A3
Type
Fixed, For 15 mm Belt Wd, Aluminum
Pitch
5 mm
Teeth
15
Finish
Clear Anodized
For Belt Series
Powerhouse®
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Timing Pulley is a curvilinear, HTD section fixed-bore timing pulley with hub, designed for the Powerhouse® belt series. It features a clear anodized finish, accommodates a 15 mm belt width, and has 15 teeth with a 5 mm pitch, constructed from aluminum (MPN 15-5M15-6A3).

Frequently Asked Questions

What is the DAYTON Timing Pulley 15-5M15-6A3 used for?

The DAYTON Timing Pulley is used in synchronous belt drive systems to transmit motion and power without slippage. It is designed for the Powerhouse® belt series, ideal for industrial machinery requiring precise timing, such as conveyors, packaging equipment, and automated manufacturing lines.

What are the specifications of the DAYTON Timing Pulley 15-5M15-6A3?

This DAYTON timing pulley is a curvilinear HTD section fixed-bore type with hub. It has 15 teeth, a 5 mm pitch, and a 15 mm belt width. Made of aluminum with a clear anodized finish, it is designed for the Powerhouse® belt series. The manufacturer part number is 15-5M15-6A3.

Where to buy the DAYTON Timing Pulley 15-5M15-6A3 worldwide?

3G Electric supplies the DAYTON Timing Pulley 15-5M15-6A3 to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us to source this pulley for your application.

How to select the correct DAYTON timing pulley for a Powerhouse® belt?

To select the correct DAYTON timing pulley, match the belt series (Powerhouse®), pitch (5 mm), and belt width (15 mm). Ensure the number of teeth (15) meets your speed and torque requirements. The fixed-bore design requires shaft size confirmation. Consult a drive design guide for proper alignment and tensioning.
