Dayton Timing Pulley: Curvilinear, Fixed, For 9 mm Belt Wd, 34 Teeth, 5 mm Pitch - HTD Section Fixed-Bore Timing Pulleys with Hub
DaytonHTD Section Fixed-Bore Timing Pulleys with Hub

Dayton Timing Pulley: Curvilinear, Fixed, For 9 mm Belt Wd, 34 Teeth, 5 mm Pitch

The DAYTON Timing Pulley is a curvilinear, fixed-bore HTD section pulley with a hub, designed for use with Powerhouse® belt series. It features 34 teeth, a 5 mm pitch, and accommodates a 9 mm belt width, with a clear…

SKU 3G-OTH-112171

Brand
Dayton
Item
Timing Pulley: Curvilinear, Fixed, For 9 mm Belt Wd, 34 Teeth, 5 mm Pitch
Category
HTD Section Fixed-Bore Timing Pulleys with Hub
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
34-5M09-6A3
Type
Fixed, For 9 mm Belt Wd, Aluminum
Pitch
5 mm
Teeth
34
Finish
Clear Anodized
For Belt Series
Powerhouse®
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Timing Pulley is a curvilinear, fixed-bore HTD section pulley with a hub, designed for use with Powerhouse® belt series. It features 34 teeth, a 5 mm pitch, and accommodates a 9 mm belt width, with a clear anodized aluminum finish (MPN 34-5M09-6A3).

Frequently Asked Questions

What is the DAYTON Timing Pulley 34-5M09-6A3 used for?

The DAYTON Timing Pulley is used in synchronous belt drive systems to transmit rotary motion precisely without slippage. It is ideal for industrial machinery, conveyors, and automation equipment that require accurate timing and positioning, particularly with Powerhouse® belt series.

What are the specifications of the DAYTON Timing Pulley 34-5M09-6A3?

This DAYTON Timing Pulley is a curvilinear, fixed-bore HTD section pulley with a hub. It has 34 teeth, a 5 mm pitch, and fits a 9 mm belt width. The pulley is made of clear anodized aluminum, with manufacturer part number 34-5M09-6A3, designed for Powerhouse® belt series.

Where to buy the DAYTON Timing Pulley 34-5M09-6A3 worldwide?

You can source the DAYTON Timing Pulley 34-5M09-6A3 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring you receive the correct OEM-sourced component for your application.

How to select the correct DAYTON Timing Pulley for a 9 mm belt?

To select the correct DAYTON Timing Pulley, match the belt width (9 mm), pitch (5 mm), and tooth profile (curvilinear HTD). Ensure the pulley bore size fits your shaft. The 34-5M09-6A3 model is a fixed-bore design with a hub, suitable for Powerhouse® belt series. Consult your drive system specifications for proper alignment.
