Dayton Timing Pulley: Curvilinear, Fixed, For 9 mm Belt Wd, 24 Teeth, 5 mm Pitch
The DAYTON Timing Pulley is a curvilinear, HTD section fixed-bore timing pulley with hub, designed for the Powerhouse® belt series. It features 24 teeth with a 5 mm pitch and accommodates a 9 mm belt width…
SKU 3G-OTH-112673
Need installation or engineering help?
Ask a question
Product Description
The DAYTON Timing Pulley is a curvilinear, HTD section fixed-bore timing pulley with hub, designed for the Powerhouse® belt series. It features 24 teeth with a 5 mm pitch and accommodates a 9 mm belt width, constructed from aluminum with a clear anodized finish. This pulley is identified by manufacturer part number 24-5M09M6A8.
Frequently Asked Questions
What is the DAYTON Timing Pulley 24-5M09M6A8 used for?
The DAYTON Timing Pulley is used in synchronous belt drive systems to transmit precise rotary motion and torque. It is designed for the Powerhouse® belt series, commonly applied in industrial machinery, packaging equipment, and automation systems requiring accurate timing and positioning.
What are the specifications of the DAYTON Timing Pulley 24-5M09M6A8?
This DAYTON pulley is an HTD section fixed-bore type with a hub, featuring 24 teeth, a 5 mm pitch, and a 9 mm belt width. It is made of aluminum with a clear anodized finish. The manufacturer part number is 24-5M09M6A8, and it is designed for the Powerhouse® belt series.
Where to buy the DAYTON Timing Pulley 24-5M09M6A8 worldwide?
You can source the DAYTON Timing Pulley 24-5M09M6A8 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this pulley.
How to select the correct DAYTON Timing Pulley for a 9 mm belt?
To select the correct DAYTON Timing Pulley, match the belt width (9 mm), pitch (5 mm), and tooth profile (HTD curvilinear). Ensure the pulley bore size fits your shaft. The 24-5M09M6A8 model is a fixed-bore design with hub, suitable for Powerhouse® series belts. Verify alignment and tension per manufacturer guidelines.
Used in
Common applications for DaytonDayton Products
3G Electric supplies Dayton htd section fixed-bore timing pulleys with hub. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
