Dayton Timing Pulley: Curvilinear, Fixed, For HTD Timing Belt Section, For 9 mm Belt Wd - HTD Section Fixed-Bore Timing Pulleys with Hub
DaytonHTD Section Fixed-Bore Timing Pulleys with Hub

Dayton Timing Pulley: Curvilinear, Fixed, For HTD Timing Belt Section, For 9 mm Belt Wd

The DAYTON Timing Pulley is a curvilinear, HTD Section Fixed-Bore Timing Pulley with Hub, designed for use with Powerhouse® belt series. It features a clear anodized finish and is specified for a 9 mm belt width with…

SKU 3G-OTH-113112

Brand
Dayton
Item
Timing Pulley: Curvilinear, Fixed, For HTD Timing Belt Section, For 9 mm Belt Wd
Category
HTD Section Fixed-Bore Timing Pulleys with Hub
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
18-5M09M6A8
Type
Fixed, For HTD Timing Belt Section, For 9 mm Belt Wd
Teeth
18
Finish
Clear Anodized
For Belt Series
Powerhouse®
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Timing Pulley is a curvilinear, HTD Section Fixed-Bore Timing Pulley with Hub, designed for use with Powerhouse® belt series. It features a clear anodized finish and is specified for a 9 mm belt width with 18 teeth (manufacturer part number 18-5M09M6A8).

Frequently Asked Questions

What is the DAYTON Timing Pulley 18-5M09M6A8 used for?

The DAYTON Timing Pulley is used in power transmission systems to synchronize motion with an HTD timing belt. It is designed for curvilinear HTD belt sections, specifically the Powerhouse® series, and is suitable for applications requiring precise timing, such as conveyor systems and industrial machinery.

What are the specifications of the DAYTON Timing Pulley 18-5M09M6A8?

The DAYTON Timing Pulley has 18 teeth, a fixed-bore design with hub, and a clear anodized finish. It is for HTD timing belt sections and fits a 9 mm belt width. The manufacturer part number is 18-5M09M6A8, and it is compatible with the Powerhouse® belt series.

Where to buy the DAYTON Timing Pulley 18-5M09M6A8 worldwide?

You can source the DAYTON Timing Pulley 18-5M09M6A8 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring you receive the correct DAYTON component for your application.

How to select the correct DAYTON timing pulley for an HTD belt?

To select the correct DAYTON timing pulley, match the belt section (HTD), belt width (9 mm), and tooth count (18) to your system requirements. Ensure the pulley bore size fits your shaft. The clear anodized finish on this DAYTON pulley provides corrosion resistance for industrial environments.
