Dayton Timing Pulley: Curvilinear, Fixed, For HTD Timing Belt Section, For 9 mm Belt Wd - HTD Section Fixed-Bore Timing Pulleys with Hub
DaytonHTD Section Fixed-Bore Timing Pulleys with Hub

Dayton Timing Pulley: Curvilinear, Fixed, For HTD Timing Belt Section, For 9 mm Belt Wd

The DAYTON Timing Pulley is a curvilinear, fixed-bore HTD section timing pulley with hub, designed for use with Powerhouse® belt series. It features a clear anodized finish and is specified for a 9 mm belt width with…

SKU 3G-OTH-113567

Brand
Dayton
Item
Timing Pulley: Curvilinear, Fixed, For HTD Timing Belt Section, For 9 mm Belt Wd
Category
HTD Section Fixed-Bore Timing Pulleys with Hub
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
15-5M09-6A3
Type
Fixed, For HTD Timing Belt Section, For 9 mm Belt Wd
Teeth
15
Finish
Clear Anodized
For Belt Series
Powerhouse®
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Timing Pulley is a curvilinear, fixed-bore HTD section timing pulley with hub, designed for use with Powerhouse® belt series. It features a clear anodized finish and is specified for a 9 mm belt width with 15 teeth (manufacturer part number 15-5M09-6A3).

Frequently Asked Questions

What is the DAYTON Timing Pulley 15-5M09-6A3 used for?

The DAYTON Timing Pulley is used in synchronous belt drive systems to transmit precise rotary motion and torque. It is designed for HTD (High Torque Drive) curvilinear belt sections, commonly applied in industrial machinery, conveyors, and automation equipment requiring accurate timing and power transfer.

What are the specifications of the DAYTON Timing Pulley 15-5M09-6A3?

This DAYTON pulley has a curvilinear, fixed-bore design with a hub, featuring 15 teeth for a 9 mm belt width. It is compatible with HTD belt section and Powerhouse® belt series. The finish is clear anodized, and the manufacturer part number is 15-5M09-6A3.

Where to buy the DAYTON Timing Pulley 15-5M09-6A3 worldwide?

3G Electric supplies the DAYTON Timing Pulley 15-5M09-6A3 to customers worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to select the correct DAYTON Timing Pulley for a 9 mm belt?

To select the correct DAYTON Timing Pulley, match the belt width (9 mm), belt section (HTD curvilinear), and tooth count (15 teeth) to your drive requirements. Ensure the fixed bore diameter fits your shaft. The clear anodized finish provides corrosion resistance. Verify compatibility with Powerhouse® belt series.
