Dayton Timing Pulley: Curvilinear, Fixed, For HTD Timing Belt Section, For 9 mm Belt Wd - HTD Section Fixed-Bore Timing Pulleys with Hub
DaytonHTD Section Fixed-Bore Timing Pulleys with Hub

Dayton Timing Pulley: Curvilinear, Fixed, For HTD Timing Belt Section, For 9 mm Belt Wd

The DAYTON Timing Pulley is a curvilinear, fixed-bore HTD section timing pulley with hub, designed for use with Powerhouse® belt series. It features 64 teeth and accommodates a 9 mm belt width, with a clear anodized…

SKU 3G-OTH-113892

Brand
Dayton
Item
Timing Pulley: Curvilinear, Fixed, For HTD Timing Belt Section, For 9 mm Belt Wd
Category
HTD Section Fixed-Bore Timing Pulleys with Hub
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
64-3M09-6A4
Type
Fixed, For HTD Timing Belt Section, For 9 mm Belt Wd
Teeth
64
Finish
Clear Anodized
For Belt Series
Powerhouse®
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Timing Pulley is a curvilinear, fixed-bore HTD section timing pulley with hub, designed for use with Powerhouse® belt series. It features 64 teeth and accommodates a 9 mm belt width, with a clear anodized finish. This pulley is identified by manufacturer part number 64-3M09-6A4.

Frequently Asked Questions

What is the DAYTON Timing Pulley 64-3M09-6A4 used for?

The DAYTON Timing Pulley is used in power transmission systems to synchronize motion with an HTD timing belt. It is ideal for industrial machinery, conveyors, and automation equipment requiring precise, slip-free torque transfer. The curvilinear tooth profile and clear anodized finish ensure durability and reduced belt wear.

What are the specifications of the DAYTON Timing Pulley 64-3M09-6A4?

This DAYTON pulley has 64 teeth, a fixed bore, and is designed for HTD timing belt section with a 9 mm belt width. It features a clear anodized finish and is compatible with the Powerhouse® belt series. The manufacturer part number is 64-3M09-6A4.

Where to buy the DAYTON Timing Pulley 64-3M09-6A4 worldwide?

You can source the DAYTON Timing Pulley 64-3M09-6A4 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to select the correct DAYTON Timing Pulley for an HTD belt?

To select the correct DAYTON Timing Pulley, match the belt section (HTD), belt width (9 mm), and tooth count (64) to your drive requirements. Ensure the bore size fits your shaft. The clear anodized finish provides corrosion resistance. For fixed-bore pulleys, confirm the hub configuration suits your mounting setup.
