Dayton Timing Pulley: Curvilinear, Fixed, For 9 mm Belt Wd, 30 Teeth, 3 mm Pitch - HTD Section Fixed-Bore Timing Pulleys with Hub
DaytonHTD Section Fixed-Bore Timing Pulleys with Hub

Dayton Timing Pulley: Curvilinear, Fixed, For 9 mm Belt Wd, 30 Teeth, 3 mm Pitch

The DAYTON Timing Pulley is a curvilinear, HTD section fixed-bore timing pulley with hub, designed for the Powerhouse® belt series. It features a clear anodized finish, accommodates a 9 mm belt width, and has 30…

SKU 3G-OTH-115981

Brand
Dayton
Item
Timing Pulley: Curvilinear, Fixed, For 9 mm Belt Wd, 30 Teeth, 3 mm Pitch
Category
HTD Section Fixed-Bore Timing Pulleys with Hub
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
30-3M09-6FA6
Type
Fixed, For 9 mm Belt Wd, Aluminum
Pitch
3 mm
Teeth
30
Finish
Clear Anodized
For Belt Series
Powerhouse®
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Timing Pulley is a curvilinear, HTD section fixed-bore timing pulley with hub, designed for the Powerhouse® belt series. It features a clear anodized finish, accommodates a 9 mm belt width, and has 30 teeth with a 3 mm pitch, constructed from aluminum (MPN 30-3M09-6FA6).

Frequently Asked Questions

What is the DAYTON Timing Pulley 30-3M09-6FA6 used for?

The DAYTON Timing Pulley is used in synchronous belt drive systems to transmit rotary motion precisely without slippage. It is designed for the Powerhouse® belt series, making it suitable for industrial machinery, conveyors, and automation equipment requiring accurate timing and positioning.

What are the specifications of the DAYTON Timing Pulley 30-3M09-6FA6?

This DAYTON timing pulley is a curvilinear HTD section fixed-bore type with hub. It has 30 teeth, a 3 mm pitch, fits a 9 mm belt width, and is made of aluminum with a clear anodized finish. The manufacturer part number is 30-3M09-6FA6.

Where to buy the DAYTON Timing Pulley 30-3M09-6FA6 worldwide?

3G Electric supplies the DAYTON Timing Pulley 30-3M09-6FA6 to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this pulley.

How to select the correct DAYTON timing pulley for a Powerhouse® belt?

To select the correct DAYTON timing pulley, match the belt series (Powerhouse®), pitch (3 mm), number of teeth (30), and belt width (9 mm). Ensure the bore size fits your shaft. The fixed-bore design with hub simplifies installation. Consult the manufacturer's catalog for compatibility.
