Dayton Timing Pulley: Curvilinear, Fixed, For HTD Timing Belt Section, For 6 mm Belt Wd - HTD Section Fixed-Bore Timing Pulleys with Hub
DaytonHTD Section Fixed-Bore Timing Pulleys with Hub

Dayton Timing Pulley: Curvilinear, Fixed, For HTD Timing Belt Section, For 6 mm Belt Wd

The DAYTON Timing Pulley is a curvilinear, fixed-bore HTD section timing pulley with hub, designed for use with Powerhouse® belt series. It features a clear anodized finish and is specified for a 6 mm belt width with…

SKU 3G-OTH-109019

Brand
Dayton
Item
Timing Pulley: Curvilinear, Fixed, For HTD Timing Belt Section, For 6 mm Belt Wd
Category
HTD Section Fixed-Bore Timing Pulleys with Hub
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

Dayton
Manufacturer Part Number
56-3M06-6A4
Type
Fixed, For HTD Timing Belt Section, For 6 mm Belt Wd
Teeth
56
Finish
Clear Anodized
For Belt Series
Powerhouse®
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

Dayton Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The DAYTON Timing Pulley is a curvilinear, fixed-bore HTD section timing pulley with hub, designed for use with Powerhouse® belt series. It features a clear anodized finish and is specified for a 6 mm belt width with 56 teeth (manufacturer part number 56-3M06-6A4).

Frequently Asked Questions

What is the DAYTON Timing Pulley 56-3M06-6A4 used for?

The DAYTON Timing Pulley is used in synchronous belt drive systems to transmit rotary motion and torque without slippage. It is designed for HTD (High Torque Drive) curvilinear belt sections, specifically for Powerhouse® belt series, making it suitable for industrial machinery, conveyors, and automation equipment requiring precise timing and load capacity.

What are the specifications of the DAYTON Timing Pulley 56-3M06-6A4?

The DAYTON Timing Pulley has 56 teeth, a fixed-bore design with hub, and is compatible with HTD timing belt sections for a 6 mm belt width. It features a clear anodized finish for corrosion resistance and is part of the Powerhouse® belt series. The manufacturer part number is 56-3M06-6A4.

Where to buy the DAYTON Timing Pulley 56-3M06-6A4 worldwide?

You can source the DAYTON Timing Pulley 56-3M06-6A4 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine DAYTON components for industrial applications.

How to select the correct DAYTON timing pulley for a Powerhouse® belt?

To select the correct DAYTON timing pulley, match the belt section type (HTD curvilinear), belt width (6 mm), and tooth count (56) to your drive requirements. Ensure the fixed-bore size accommodates your shaft diameter. The clear anodized finish provides durability. For assistance, consult 3G Electric for sourcing the exact part number 56-3M06-6A4.
